Late 2015 to 2016 Land Rover vehicles with InControl, Version 4 radio.
1. Only for vehicles WITHOUT factory rear-view camera.
“InControl” Touch Screen Navigaon radios, Version 4.
LR-68C Harness
RVCLR-68C
CAN Interface
Fakra Adaptor
1 / 5
Version 1
Version 2
Version 3
Version 4
031516
Please note that the given informaon must be
veried by the installer. Crux Interfacing assumes no
liability for changes in wire color or pin assignments
made by the vehicle manufacturer.
Funcon
Pin-No.
CAN-HIGH (Yellow)
Pin 3 (chamber B)
CAN-LOW (Blue)
Pin 9 (chamber B)
+12V Constant (Red)
Pin 13
Ground (Black)
Pin 11
031516
2 5 /
Video- -Moon (Selecve) (Green Wire) In
DIP Switch Seng
Vehicle/ navigaon
Dip 1
Dip 2
Dip 3
Dip 4
Dip 5
Dip 6
Video-in-moon permanent
ON
OFF
OFF
OFF
ON
ON
Video-in-moon selecve*
OFF
OFF
OFF
OFF
ON
ON
*With DIP1 set to OFF, the Green wire is used to acvate the video- -moon funcon. in
DIP switch funcons
Dip 1 (ON / OFF Acvate Video- -Moon ) In
Dip 2 (OFF) Factory Rear-view camera present
Dip 3 (OFF) no funcon
Dip 4 (OFF) no funcon
Dip 5 (ON) CAN-bus terminaon resistor on the vehicle side
Dip 6 (ON) CAN-bus terminaon resistor on the headunit side
Seng DIP 2 to ON codes the factory rear-view camera input which is located on the blue
double Fakra male connector of the head unit. When reverse gear is engaged, the navigaon
will automacally switch to this input.
Connecng the RVCLR-86C to the Headunit
Connect female 8 Pin Molex
connector of the LR-86C
harness to male 8 Pin Molex
connector of the Module.
Transfer Quadlock connector
of vehicle harness from rear of
the headunit into the male
Quadlock connector of the
LR-86C harness.
Plug female Quadlock
connector of the LR-86C
harness into male Quadlock
socket on the rear of the
headunit.
1
2
3
1
2
3
031516
3 / 5
