SteadiCam M-2 Manual
Read below 📖 the manual in Italian for SteadiCam M-2 (54 pages) in the Tripod category. This guide has been helpful for 150 people and has been rated 4.5 stars on average by 2 users
Page 1/54
LIT-888000, RevA
Steadicam
®
M-2
â„¢
System Manual
4 Evolution of the Steadicam M-Series
5 Steadicam modular components map
6 Stage components
7 Inputs and outputs
8 Camera dovetail clamp
10 Balance drives
11 Tilt stage
12 Volt system operation
16 Adjustments and maintenance
18 Installing Volt electronics
19 Installing or moving Volt control boxes
22 Post components
23 Post lock adjustment
24 Separating and connecting modular parts
28 Gimbal components
29 Gimbal with Volt components
30 M-2 Volt compared to M-1 Volt
31 Gimbal clamp adjustment
32 Pan bearing removal and cleaning
34 Pan bearing replacement
36 Monitor mount components
37 Monitor mount positioning
38 Clamp operation
39 Monitor yoke adjustment
40 Adjusting monitor clamps and hinge brakes
42 Base and battery mount components
43 Base electronics
44 Battery positioning
45 Installing the 3
rd
battery mount
46 Three batteries, three switches
48 Connector diagrams and warnings
49 M-1 and M-2 features and specs
50 M-1 and M-2 part numbers
52 M-1 and M-2 accessories list
54 Contact Tiffen
