Page 1/3
This Fixture is Dry Rated
1. Decide the preferred hanging height and
choose the correct of rods needed.number of
2. Feed the wires through the rods,screw collar
ring a and canopy (with bigger center hole).
Screw the rods together. Screw one end of the
rod assembly onto the top of frame and the
other end onto the swivel on the mounting
strap.
3. Attach the mounting strap onto the outlet box.
4. Raise the fixture up to the ceiling and do the
wire connections Slip the canopy up along the.
rods and over the mounting strap. Secure with
the screw collar ring.
5. Install the bulb the socket.into
6. Dress the glass as illustrated.
Glass Sets
1. 24 pcs 2 3/4x7 3/4”Various colored glass
Crystorama.com
For Pendant
4
ADD-300-AG-AU
1
5
3
2
6
Ø130 [5
1
8
"]
25 [1"]
349 [133
4"]
Ø446 [Ø17
5
8
"]
Ø13 [
1
2
"]
STEMS (3-12")
STEMS (1-6")
24PCS
4
Tier#1
Tier#2
Tier#3
Tier#4
Dress the glass from tier #4.
How to Install
How to Install
1. Screw the canopy kit (with smaller center a
hole) onto the frame.
2. Attach the mounting strap onto the outlet box.
3. Raise the fixture up to the ceiling and over the
mounting strap. When the wire connection is
made ecure the canopy with two ball nuts., s
4. Install the bulb i
nto the socket.
5. Dress the glass as illustrated.
Glass Sets
1. 24 pcs Clear glass 2 3/4x7 3/4”
Crystorama.com
For Ceiling
2
5
4
3
1
Ø130 [5
1
8
"]
25 [1"]
349 [133
4"]
Ø446 [Ø17
5
8
"]
6
24PCS
4
ADD-300-AG-AU
A. (1)-Canopy,D 5 1/8XH1”
XBN300 CAN5.125INAG
B. (1)-Collar ring
C. (1)-Swivel
D. AG(1) - 6" Rod - XBN300 ROD6IN
E. AG(3) - 12" Rods - XBN300 ROD12IN
F.
G.
(1)-Frame
(24)
-Glass,D2 3/4xH7 3/4"
XBN300 GLA7.75INAGAM
Crystorama.com
ADD-300-AG-AU
A
B
C
D
E
F
Product Specifications
