Page 1/2
#
KAR-90903-AG-CL-MWP
You will need 3 Candelabra Base Bulb
60 Watts Recommended 60 Watts Max.
USE LED BULBS FOR EXTENDED USE( This fixture is Dry rated)
How to Install
Please place the fixture parts on a soft-cloth covered platform
before installation. Do not remove the packaging on the arms
until after installation is completed.
.
1.
2.
3.
5.
4.
Open the quick link at the end of the chain and fasten the
chain to the fixture loop. Fasten mounting hardware to
junction box with the machine screws. After the wires are
connected, screw the screw collar loop onto the nipple.
Place the canopy up against the ceiling and secure by
tightening the screw collar loop ring.
After safely attaching the fixture onto the junction box, place
the crystal bobeche onto the lamp holder,then install the bulbs
and proceed to connecting the power.
When you begin to dress the fixture, start with package
labeled(A).
IMPORTANT:Apply crystal sets in alphabetical order.
Crystorama.com
Crystal sets
A. 3sets 1*14mm+1*63mm drop
B. 3sets 2*14mm+1*63mm drop
C. 3sets 14*14mm
D. 3sets 19*14mm
E. 3sets 11*14mm
F. 1set 17*14mm+1*40mm
1
A=3PCS
C=3PCS
B=3PCS
D=3PCS
E=3PCS
F=1PCS
∅136 [5
3
8
"]
23 [
7
8
"]
䌙 䌙356 [ 14"]
533 [21"]
2413[95"]
A. (1)-Mounting Hardware
(XBN90903AGCAN5.375IN)
B. (1)-Canopy,D5 3/8 X H 7/8”
C. (1)-Collar loop
D. (1)-Chain,L72”
(XBN90903AGCHA4MM)
E. (3)-Scroll arms,L3 3/4”
F.
(3)
-Candle sleeve,L3 1/2"
(XBN90902AGCDL3.5IN)
G. (3)-Crystal Bobeche,D 2 3/8”
(XBN90902BOB2.375IN )
H
. (1)-Fixture loop
KAR-90903-AG-CL-MWP
Crystorama.com
A
B
C
D
E
F
G
H
