Gamdias Talos M1B Manual

Read below 📖 the manual in Italian for Gamdias Talos M1B (19 pages) in the Not categorized category. This guide has been helpful for 28 people and has been rated 4.5 stars on average by 2 users

Page 1/19
QUICK
INSTALLATION
GUIDE
M1B
Talos
MID-TOWER PC CASE
TABLE OF
CONTENTS
1Specifications
2Exploded View & Parts
3Accessory
4Side Panel Removal
5Motherboard Installation
6PSU Installation
73.5" & 2.5" HDD Installation
8PCI-E / PCI Card(S) Usage
9Air Cooling Compatibility
10 Radiator Compatibility
11I/O Ports
12I/O Connectors
13RGB Fan Controller Installation
SPECIFICATIONS
Model Name
Dimensions (H x W x D )
Case Type
Material(s)
Side Panel
Motherboard Support
LOGO Light
Panel Light
IO Port
Expansion Slots
Drive Bays
Radiator Support
Fan Support
PSU
Clearance
448 x 210 x 466 mm
17.6 x 8.3 x 18.3 inch
MID Tower
Tempered Glass, SPCC, ABS
4mm Tempered Glass x 2
(Left & Front)
6.7" x 6.7" (Mini ITX),
9.6" x 9.6" (Micro ATX),
12" x 9.6" (ATX)
Yellow LED
7 Colors
USB3.0 x 2, USB2.0 x 2, Mic,
Headphone, Fan LED Control,
Speed Controller
7 + 2
2 x 3.5" or 2 x 2.5"(HDD Cage)
2 x 2.5"
Front: 1 x 360mm, 1 x 280mm
Rear: 1 x 120mm
Front: 3 x 120mm, 2 x 140mm
Top: 2 x 120mm, 2 x 140mm
Rear: 1 x 120mm, 1 x 140mm
ATX PS2
CPU cooler height limitation: 168mm
VGA length limitation: 350mm
PSU length limitation: 180mm
TALOS M1B

Product Specifications

Brand: Gamdias
Category: Not categorized
Model: Talos M1B
