Page 1/13
GLONASS AVL Tracking System
TR-600G
GlobalSat WorldCom Corporation
16F., No. 186, Jian 1
st
Rd, Zhonghe Dist.,
New Taipei City 23553, Taiwan
Tel: 886.2.8226.3799/ Fax: 886.2.8226.3899
service@globalsat.com.tw
www.globalsat.com.tw
USGlobalSat Incorporated
14740 Yorba Court Chino, CA 91710
Tel: 888.323.8720 / Fax:
909.597.8532
sales@usglobalsat.com
www.usglobalsat.com
2
CONTENT
1. Introduction ....................................................................................................................................... 3
1.1 Introduction ............................................................................................................................. 3
1.2 Features .................................................................................................................................... 3
1.3 Hardware Architecture ........................................................................................................ 4
1.4 Hardware specification ........................................................................................................ 5
1.5 Appearance .............................................................................................................................. 6
1.6 LED indicator ........................................................................................................................... 7
1.7 Cable description ................................................................................................................... 8
1.8 Accessories ............................................................................................................................ 10
2 Operation ............................................................................................................................................ 11
2.1 Install the SIM card ............................................................................................................ 11
2.2 Install the GPS and GSM antenna ................................................................................ 12
2.3 Installing the Emergency button ................................................................................... 13
3
1. Introduction
1.1 Introduction
TR-600G is a multi-functional and economical communication platform for mobile positioning
applications. It integrates high sensitivity GPS/GLONASS/GALILEO module and Quad-band
850/900/1800/1900 GSM communication module with powerful microcontroller into a compact
board. TR-600G enclosed into a solid housing for simple installation. It provides Real Time
GPS/GLONASS/GALILEO positions anytime and anywhere in the open sky and offer the
precise position and vehicle status to control computer to display the necessary information
onto the maps. Benefits such as enhanced fleet management, improved vehicle safety, useful
emergency response, and goods/items transformation are all accomplished through the
implementation of TR-600G system.
1.2 Features
Quad-band GSM/GPRS/EDGE 850/900/1800/1900 MHz system
Built-in high sensitivity GPS/GLONASS system with active antenna.
Supports AT command via SMS/ TCP/UDP
Remote control via SMS/GPRS command
Real-time GPS position feedback and vehicle status monitoring
Built-in in digital outputs (3), digital inputs (3), an ACC input, 1 analog input, and 1 serial
port
Power supply for Li-ion battery and lead-acid battery
Supports multi geo-fence function
OTA (Over the air) firmware upgrade
Data buffer storage 3,000 points
Interval report depends on customization
Power low/lost detection alarm
Motion sensor
3 LED indicators for GSM, GPS, power status
