Haier HWOS60S4MB1 Manual
Read below 📖 the manual in Italian for Haier HWOS60S4MB1 (26 pages) in the Oven category. This guide has been helpful for 12 people and has been rated 4.5 stars on average by 2 users
Page 1/26
HWOS60S4MB1
60cm
INSTALLATION AND USER GUIDE
NZ AU
Built-in Side Opening Oven
2 3
SAFETY INSTRUCTIONS
The appliance is not intended for use by persons (including children) with reduced
physical, sensory or mental capabilities, or lack experience and knowledge, unless
they have been given supervision for their safety.
Do not use harsh abrasive cleaners, scourers or sharp metal scrapers to clean the
door glass as they can scratch the surface which may result in glass shattering.
Do not use the oven in the event of a technical fault. If a technical fault occurs,
disconnect the power and report the fault to the service centre for repair.
The rules and provisions contained in this instruction manual should be strictly
observed. Do not allow anybody who is not familiar with the contents of this
instruction manual to operate the oven.
Never clean the oven with the high-pressure steam cleaning device, as it may cause
short a circuit.
If the supply cord is damaged, it must be replaced by the manufacturer, its service
agent or similarly qualified persons in order to avoid a hazard.
WARNING Ensure that the appliance is switched off before replacing the lamp to:
avoid the possibility of ELECTRIC shock.
Mains lead of adjacent appliances may be damaged by hobs or stuck between the
oven doors, and produce short circuit, therefore keep them at safe distance from the
appliance.
When the input voltage exceeds 270V, the oven will automatically shutdown. The
user will need to manually restart the oven.
During unpacking, the packaging materials (polythene bags, polystyrene pieces, etc.)
Do not place aluminium foil, dishes or trays, water or ice on the oven floor during
cooking, as doing so will irreversibly damage the enamel. Lining the oven with
aluminium foil may even cause fire.
should be kept out of reach of children.
During use the appliance becomes hot. Care should be taken to avoid touching
heating elements inside the oven.
Warning: Accessible parts may become hot during use. Young children should be
kept away.
Excess spillage must be removed before cleaning.
The appliance must not be installed behind a decorative door in order to avoid
overheating.
Children should be supervised to ensure that they do not play with the appliance.
The fixed wiring installation must be incorporated with an all poles disconnection
device in accordance with the wiring rules that provide full disconnection under
overvoltage category III conditions.
CONTENTS
SAFETY INSTRUCTIONS ............................... ......... .................. .. .......... . . . ..................... 3
HOW TO SAVE ENERGY ............................... ......... .................. .. .......... . . . ..................... 4
PACKAGING ............................... ............................ .. ......... .................. .. ......... ........ . . . . . . . 4
DISPOSAL OF THE APPLIANCE ............................ ... .......... .................. .. ......... ........ . . . . 4
DESCRIPTION OF THE APPLIANCE ................... ........... ......... .................. .. .......... . . . . ... 5
INSTALLATION ............................... ......... .................. .. ......... .................. .. ......... .... . . . . . . . . 6
OPERATION ............................... ............................ .. ......... .................. .. ......... ........ . . . . . . . 9
BAKING IN THE OVEN ............................... ......... .................. ... . . .......... .................. ... . . 12
CLEANING AND MAINTENANCE ................... ........... ......... .................. .. .......... . . . . ...... 18
OPERATION IN CASE OF EMERGANCY ......... .................. .. ......... .................. .. ... . . . . . . 21
TROUBLESHOOTING ............................ .. ......... .................. .. ......... .................. ... . . . . . . .. 21
TECHNICAL INFORMATION ................... ........... ......... .................. .. ......... ............. . . . . . . 22
MANUFACTURER’S WARRANTY ................... ........... ......... .................. .. ......... ..... . . . . . . 23
CUSTOMER CARE ............................... ................... ........... ......... .................. .. ...... . . . . . . 24
4 5
HOW TO SAVE ENERGY
DISPOSAL OF THE APPLIANCE
PACKAGING
Using energy in a responsible way not only saves money but also helps the environment.
So, let's save energy, and this is how you can do it:
Make use of residual heat from the oven. If the cooking time is greater than 40 minutes,
switch off the oven 10 minutes before the end time. When using the timer, set appropriately
shorter cooking times according to the dish being prepared where possible.
Old appliances should not simply be disposed of with normal household waste, but
should be delivered to a collection and recycling centre for electric/electronic
equipment.
A symbol shown on the product, the instruction manual or the packaging shows that
it is suitable for recycling.
Some materials used inside the appliance are recyclable. Recycling materials or other
parts from used devices that will make a significant contribution to the protection of our
environment if recycled appropriately. Information on appropriate disposal centres for
used devices can be provided by your local authority.
Make sure the oven door is closed properly. Cooking residues/spillages left on the door
seal can cause the door not to close with a tight seal, which can cause heat to escape
from the oven. Clean up any spillages immediately.
During transportation, protective packaging was used to protect the appliance against any
damage. After unpacking, please dispose of all elements of packaging in a way that will
not cause harm to the environment.
DESCRIPTION OF THE APPLIANCE
Temperature Control Dial
Mechanical Timer
Oven Function Selection Dial
Number
Parts
Quantity
Wire Shelves
Oven Door Handle
Oven Temperature Indicator
Oven Door
Baking Tray
2
3
4
5
7
6
1
8
1 1
1
1
1
1
1
1
1
2
3
4
5
6
7
8
Product Specifications
| Brand: | Haier |
| Category: | Oven |
| Model: | HWOS60S4MB1 |
