Page 1/12
model / 型号
GC9122
P/N: 40-50965-00
Gas Cooker / 燃气炉 / Dapur Gas
Instruction Manual / Buku Panduan说明指示书/
Please read this manual carefully before operating this product. Keep this manual handy for further reference.
请在使用此产品前 详读此说明书。并将之收藏以作日后参考。,
Sila baca buku panduan ini dengan teliti sebelum menggunakan produk ini. Simpanlah untuk rujukan masa depan.
Important / / 重要 Mustahak
This manual is also available online
www.khind.com.my
Safety Precaution
1
1. Gas used is LPG.
2. Use only approved Low Pressure Regulator.
3. Use only hose specially made for Liquefied Petroleum Gas supplies and the hose must not crack
due to aging. The hose must not come into contact with any part of the gas cooker body.
4. Before using, check to ensure that the trivet stand are placed correctly.
5. Do not use this appliance for drying clothes, etc.
6. Always maintain proper ventilation in cooking area at all times.
7. If a gas leak is found, stop the gas supply by turning the regulator control lever upward. Open all
windows for ventilation. Do not light matches or use a lighter and refrain from turning electrical
switches on and off during this period. Contact a qualified technician immediately.
8. This appliance is not intended for use by persons (including children) with reduced physical,
sensory or mental capabilities, or lack of experience and knowledge, unless they have been given
supervision or instruction concerning use of the appliance by a person responsible for their safety.
Children should be supervised to ensure that they do not play with the appliance.
9. Turn off the appliance whenever not in use.
10. Do not put flammable items on top of this appliance.
11. Do not touch metal parts of the appliance and the middle area of the top surface during and after
cooking as these areas reach high temperature.
Cleaning and Maintenance
Parts Identication
1. Always allow the appliance to cool before cleaning.
2. Use soft cloth with warm soap water for general cleaning.
3. Do not use caustic solutions, washing soda, aerosol spray cleaners, bleach and other abrasive
chemicals for cleaning.
4. DO NOT attempt to clean burner surface when still hot.
Low Pressure Regulator
High Pressure Regulator
Specications
Installation
2
Model
Burner Size
Product Category
Gas Type
Gas Pressure
Total Heat Input
Gas Power Consumption
Net Weight
Product Dimension (LxWxH)
:
:
:
:
:
:
:
:
:
GC9122
Left: 130mm; Right: 130mm
I3B/P(30)
LPG
3000Pa / 30mBar
10.4kW
Left: 5.2kW; Right: 5.2kW
6.8kg
700 x 400 x 190mm
1. This appliance should be installed by a qualified person to avoid hazards.
2. Connect the hose to the gas regulator
and LPG inlet pipe .Tighten the hose with
the butterfly clip.
3. Make sure the hose does not pass over or come in contact
with the body of the appliance.
4. Insert regulator onto outlet valve of LPG cylinder.
5. Turn regulator control lever downward to release LPG into the
appliance.
6. After installation,test with soapy water for gas leaks.
7. Do not use connecting hose that is longer than 2 metres.
8. Ensure Minimum Clearance distance 150mm from the wall and 1 meter from the ceiling.
Hose
Screw Hose Clip
OK
To Gas Regulator
LPG inlet pipe
*Specifications are subject to change
without prior notice.
Trivet Stand
Flame Adjustment Knob
Rubber Feet
1. Turn on the gas supply from the LPG cylinder by turning the
regulator control lever downwards. Make sure the knob of the
appliance is at off position.
2. Press the ignitor knob and turn it anti-clockwise. Continue to
press the knob for 3-8 seconds,let go after the burner is on.
3. Air may be accumulated in the gas hose during installation. You may have to repeat above
procedure several times initially.
4. For maximum cooking heat, turn Flame Adjustable Knob to
“MAX” position.
5. For minimum cooking heat, turn Flame Adjustable Knob to
“MIN” position.
How to Use
Troubleshooting
3 4
Problems
Ignition Failed
Other Problems
a. The valve is not opened
Open the gas valve and supply the gas.
b. The rubber hose is bent
Straighten it or replace with a new hose.
c. No gas in the cylinder
Replace with a new gas cylinder.
a. There is gas leakage from the gas pipe
Please send to nearby service center.
b. The rubber hose is broken
Replace the rubber hose.
c. There is no flame
Ignite again.
d. The nozzle or the burner is blocked
Pass through the blockage with a wire.
e. There is air inside the hose
Open the nozzle, and then release the air.
Observation Problem - Solving
重要指示
清洗及保养
零件名称
1. 使用液化石油气。
2. 只可用低压调控制。
3. 只可用适合液化石油的管。确保它没有跟燃气炉任何部分接触。
4. 使用前请确保火炉架已安装好。
5. 别用此器具烘乾衣物。
6. 烹煮环境需确保空气循环良好。
7. 如发现石油气外漏，将煤气调控制杆往上转以便把石油气关上。将窗子打开。别点燃火柴及打
火机，或开关任何电器。尽快联络技术人员。
8. 此燃气炉不适合这些人士使用；小孩，体力弱及感官，精神上有障礙，缺少经验及知识者；除
非有人监督或指示如何操作，并负责操作人的安全。
小孩需紧密的监督，此燃气炉严禁被小孩当玩具玩。
9. 不需要使用时，请关闭此燃气炉。
10. 不要把易燃物品放置在此燃气炉顶部上。
11. 在烹饪中和完成后，请勿触摸此燃气炉的金属部件和两个炉灶中间的地方，因这些地方的温度
很高。
1. 清洗前确保器具已冷却。
2. 用软布和温肥皂水清洗。
3. 不要使用强烈的清洗剂或漂白剂清洗燃气炉。
4. 严禁清洗炽热的炉头。
低压调控制 高压调控制
OFF
OFF
火炉架
火焰控制旋钮
橡胶炉脚
