Page 1/26
ECBN 786
Operating instructions Page 2
NoFrost combined refrigerator-freezer
Installation instructions Page 16
7083 450-00
Safety instructions and warnings
• To prevent injury or damage to the unit, the ap-
pliance should be unpacked and set up by two
people.
• In the event that the appliance is damaged on
delivery, contact the supplier immediately before
connecting to the mains.
• To guarantee safe operation, ensure that the ap-
pliance is set up and connected as described in
these operating instructions.
• Disconnect the appliance from the mains if any
fault occurs. Pull out the plug, switch off or remove
the fuse.
• When disconnecting the appliance, pull on the
plug, not on the cable.
• Any repairs and work on the appliance should
only be carried out by the customer service
department, as unauthor ised work could prove
highly dangerous for the user. The same applies
to changing the mains power cable.
• Do not allow naked flames or ignition sources
to enter the appliance. When transporting and
cleaning the appliance ensure that the refrigerant
circuit is not damaged. In the event of damage,
make sure that there are no ignition sources
nearby and keep the room well ventilated.
• Do not stand on the plinth, drawers or doors or
use them to support anything else.
• This appliance can be used by children of 8 years
old and over, and also by persons with restricted
physical, sensory or mental capacity or lack of
experience and knowledge, if they are supervised
or have been instructed on safe use of the appli-
ance and understand the resulting risks. Children
must not be allowed to play with the appliance.
Cleaning and user maintenance must not be
carried out by children without supervision.
• Avoid prolonged skin contact with cold surfaces or
chilled/frozen food. This could cause pain, numb-
ness and frostbite. In the case of prolonged skin
contact, protective measures should be taken,
e.g. gloves should be worn.
• Do not eat ice cream, particulary ice lollies or ice
cubes, immediately after taking them from the
freezer compartment as there is a risk of "burn-
ing" because of the very cold temperatures.
• Do not consume food which has been stored for
too long, as it could cause food poisoning.
• Do not store explosives or sprays using com-
bustible propellants such as butane, propane,
pentane etc. in the appliance. Electrical compo-
nents might cause leaking gas to ignite. You may
identify such sprays by the printed contents or a
flame symbol.
• Do not use electrical appliances inside the ap-
pliance.
• The appliance is designed for use in enclosed
areas. Do not operate the appliance outdoors or
in areas where it is exposed to splash water or
damp conditions.
• The LED light strips illuminate the interior of the
appliance. They are not suitable for lighting a
room.
Disposal notes
The appliance contains reusable materials and should
be disposed of properly - not simply with unsorted
household refuse. Appliances which are no longer
needed must be disposed of in a professional and
appropriate way, in accordance with the current local
regulations and laws.
When disposing of the appliance, ensure that the refrigerant circuit
is not damaged to prevent uncontrolled escape of the refrigerant
it contains (data on type plate) and oil.
• Disable the appliance.
• Pull out the mains plug.
• Cut through the connection cable.
WARNING
Danger of suffocation due to packing material
and plastic film!
Do not allow children to play with packaging
material.
Take the packaging material to an official collec-
tion point.
EPREL database
As from 1 March 2021, information about energy labelling and
ecodesign requirements will be available in the European product
database (EPREL). You can access the product database using
the following link: https://eprel.ec.europa.eu/. You will be asked
to enter the model identifier. You will find the model identifier on
the type plate.
2
EN
Description of the appliance
(1) Operating and control elements
(2) Adjustable door racks
(3) Adjustable storage shelves
(4) Bottle racks
(5) Type plate (behind the vegetable drawer on the left-hand side)
(6) Vegetable drawers
(7) Water filter
(8) Upper freezer drawer
(9) Lower freezer drawer
(10) IceMaker (in the interior of the upper freezer drawer)
(11) Ventilation grille. In this area, the exchange of air for the refrigera-
tion unit takes place.
Never cover this grille or otherwise obstruct
the air flow!
Freezer operating icons
Temperature setting icons
Freezer ON/OFF
SuperFrost
IceMaker ON/OFF
Refrigerator
operating icons
Refrigerator operating icons
Mute alarm (refrigerator and freezer)
SuperCool
Refrigerator ON/OFF
Temperature setting buttons
Freezer
operating icons
Control icons
Power failure LED
Dust filter LED
The dust filter in the appliance
plinth must be cleaned.
SuperCool LED
Child lock LED
Alarm LED
IceMaker ON LED
SuperFrost LED
Control
icons
Temperature and control display
Refrigerator temperature display
Freezer temperature display
Water filter has to be changed
Menu mode is activated
(for setting additional functions)
Operating and control elements
The electronic control panel has the "touch capacitance
technology". Any function can be activated by touching the
corresponding icon.
The exact contact point
is between the symbol and its label
3
Product Specifications
| Brand: | Liebherr |
| Category: | Refrigerator |
| Model: | ECN 7860 |
