Read below 📖 the manual in Italian for Liebherr SRFvg 3501 (9 pages) in the Refrigerator category. This guide has been helpful for 22 people and has been rated 4.5 stars on average by 2 users
Page 1/9
使用说明
Quality, Design and Innovation
home.liebherr.com/fridge-manuals
内容
1 设备一览................................................................. 3
1.1 发货范围......................................................................... 3
1.2 冰箱和装备一览............................................................. 3
1.3 特殊装备......................................................................... 3
1.4 设备的使用范围............................................................. 3
1.5 冰箱的噪声排放............................................................. 4
1.6 一致性............................................................................. 4
1.7 REACH 法规定义下的 SVHC 物质................................ 4
2 一般安全提示.......................................................... 4
3 Touch 显示屏工作原理............................................ 5
3.1 导航和符号说明............................................................. 5
3.2 菜单................................................................................. 5
3.3 睡眠模式......................................................................... 6
4 投入使用................................................................. 6
4.1 安装条件......................................................................... 6
4.2 冰箱尺寸......................................................................... 7
4.3 运输设备......................................................................... 7
4.4 拆开冰箱包装................................................................. 7
4.5 移除运输保险装置......................................................... 7
4.6 安装门把手..................................................................... 7
4.7 安装防翻保险................................................................. 7
4.8 放置冰箱......................................................................... 8
4.9 调整冰箱......................................................................... 9
4.10 安放多台设备................................................................. 9
4.11 完成安放后..................................................................... 9
4.12 处理包装......................................................................... 9
4.13 更换门止挡..................................................................... 9
4.14 校准冰箱门..................................................................... 16
4.15 连接设备......................................................................... 17
4.16 开启冰箱（首次调试）................................................. 17
5 存放........................................................................ 17
5.1 存放提示......................................................................... 17
6 操作........................................................................ 18
6.1 冰箱功能......................................................................... 18
6.1.1 冰箱功能提示..............................................................18
6.1.2 关闭和开启冰箱 .........................................................18
6.1.3 温度 ............................................................................ 18
6.1.4 温度记录 .....................................................................18
6.1.5 照明 *...........................................................................19
6.1.6 设置菜单访问安全性 ................................................. 19
6.1.7 访问码.........................................................................20
6.1.8 维护间隔提醒..............................................................21
6.1.9 语言 .............................................................................21
6.1.10 温度单位.....................................................................21
6.1.11 显示亮度 ................................................................... 22
6.1.12 Alarm Sound.............................................................. 22
6.1.13 Key Sound.................................................................. 22
6.1.14 WLAN 连接 ................................................................ 23
6.1.15 LAN 连接 ....................................................................24
6.1.16 冰箱信息 ................................................................... 24
6.1.17 运行小时 .................................................................... 25
6.1.18 软件 ........................................................................... 25
6.1.19 除霜 ............................................................................ 25
6.1.20 传感器校准 ................................................................ 26
6.1.21 温度警报 .................................................................... 26
6.1.22 门开警报 ....................................................................27
6.1.23 灯光警报 *.................................................................. 28
6.1.24 警报模拟 .................................................................... 28
6.1.25 警报转发 .................................................................... 29
6.1.26 演示模式.................................................................... 29
6.1.27 恢复出厂设置 ........................................................... 30
6.2 信息................................................................................. 30
6.2.1 警告.............................................................................30
6.2.2 提醒............................................................................. 32
7 装备........................................................................ 33
7.1 安全锁............................................................................. 33
7.2 传感器............................................................................. 33
7.3 接口................................................................................. 33
8 维护........................................................................ 34
8.1 维护计划......................................................................... 34
8.2 给冰箱除霜..................................................................... 35
8.3 清洁冰箱......................................................................... 35
9 客户帮助................................................................. 36
9.1 技术数据......................................................................... 36
9.2 技术故障......................................................................... 36
9.3 客户服务部门................................................................. 37
9.4 铭牌................................................................................. 37
10 停机........................................................................ 37
11 废弃处理................................................................. 37
11.1 设备废弃处理准备......................................................... 37
11.2 以环保方式对设备进行废弃处理.................................. 37
12 附加信息................................................................. 37
13 产品中有害物质的名称及含量................................. 38
14 日常使用的快门入门指南........................................ 41
制造商不断致力于各型号和品牌的进一步开发。所以请您理
解，我们必须保留在样式、装备和技术上进行修改的权利。
符号
说明
阅读说明书
为了了解您的新冰箱的所有优点，请仔细阅读本
说明书中的提示。
线上的补充信息
您 可 通 过扫描说明书封面上的二维码或在
home.liebherr.com/fridge-manuals 输 入服务
代号在线查看带有附加信息和其他语言版本的电
子说明书。
服务代号请参阅铭牌：
Fig.例图
检查冰箱
检查所有部件是否有运输损坏。如有投诉，请您
联系经销商或客户服务部。
偏差
本说明书适用于多个型号，可能存在偏差。仅适
用于特定冰箱的段落用星号 (*) 标注。
操作说明和操作结果
操作说明用 标注。
操作结果用 标注。
视频
在 Liebherr-Hausgeräte 的 YouTube 频道上有冰
箱视频可供使用。
本使用说明书适用于：
-
SRFvg 3501
-
SRFvg 3511
-
SRFvg 4001
-
SRFvg 4011
-
SRFvg 5501
-
SRFvg 5511
2 * 按冰箱型号配置
1 设备一览
1.1 发货范围
检查所有部件是否有运输损坏。如有投诉，请联系经销商或客
户服务部门。 (参见 9.3客户服务部门)
发货范围包括：
-
立式冰箱
-
装备 *
-
安装材料 *
-
使用说明
-
服务手册
-
质量证书 *
-
电源线
-
把手，包括螺钉和梅花扳手
-
壁装固定套件
1.2 冰箱和装备一览
SRFvg 3501
SRFvg 4001
SRFvg 5501
SRFvg 3511
SRFvg 4011
SRFvg 5511
Fig.1
例图
装备
(1)
铭牌 (5) 锁
(2) 存放格栅 (6) 控制元件和温度显示
(3) 垫脚 (7) 安全恒温器传感器
(4) 内部照明装置 * (8) 冷凝水排放
Fig.2
背面例图
装备
(1)
LAN/WLAN 接口 * (3) 抬升辅助装置
(2) 无电势警报输出端
1.3 特殊装备
提示
您 可 以 通 过 客 服 ( 参 见 9.3 客户服务部门) 和 Liebherr-
Hausgeräte 网 店 购买附件，网址为 home.liebherr.com/
shop/de/deu/zubehor.html。
SmartModule
冰箱可以配备一个 SmartModule。
它是冰箱和外部文件以及报警系统之间连接的 WLAN 和 LAN
接口，例如：Liebherr SmartMonitoring。
Liebherr SmartMonitoring Dashboard 并非在所有国家和地
区均可用。请您先扫描二维码 (参见 6.1.14 WLAN 连接 ) ，接
着输入冰箱的型号检查是否可用。
抽屉的加装
在加装用于存储温度敏感材料，例如：冷藏药品和需要符合特
殊标准要求的冷藏物品的 Liebherr 冰箱/冷冻机中的抽屉系统
时，需要进行温度鉴定。对 Liebherr 冰箱/冷冻机中的抽屉加
装可能会导致储存物品变质或储存物品的损坏。因此，加装只
能由冰箱/冷冻机制造商授权的服务提供者执行。
1.4 设备的使用范围
规定使用
这种实验室冰箱适合在 3 °C 到 16 °C 的温度范
围内进行产品的专业存放。
可存放的典型产品有研究样本、试剂、实验室库
存等。
在存放对温度敏感的物质时，需要使用独立的、
可持续监控的警报系统。该警报系统在设计上必
须能使负责人登记每一个警报状态，从而可以采
取相应的措施。
可预见误用
请勿将冰箱用于以下用途：
-
储存和冷却：
•
化学性质不稳定、易燃或腐蚀性物质
•
用于输入、应用或引入到人体中的血液、血
浆或其他体液。
-
应用在具有爆炸危险的区域。
-
应用在户外或潮湿和溅水区域中。
冰箱使用不当会导致存放货物的损坏或变质。
气候等级
设备一览
* 按冰箱型号配置 3
