Page 1/6
Owner’s
Manual
Travel Tripod
TR-13
Opening the Tripod
Fold the legs down
until the angle locks
click into place. Make
sure all the legs are set
to the same angle.
Open the flip locks, and
extend each leg to the
desired height. Relock
each leg.
Always extend the legs from
the top flip-locks first.
To adjust the leg angles, slightly
fold each leg down, and press
the leg angle lock. Move the leg
to the new angle, and release
the lock.
Mounting the Quick-Release Plate to the Camera
Loosen the quick-release locking knob, and remove
the quick-release plate from the ballhead.
Screw the quick-release plate into the camera’s tripod
socket until snug.
Make sure the mounting
screw’s D-ring is off to
the side of the screw.
Mount the camera/quick-
release plate assembly to
the ballhead by placing
the grooved edges of the
quick-release plate into
the matching beveled
sides of the ballhead.
Tighten the quick-release
locking knob until the
assembly is secure.
1
2
1
2
3
4
Operating the
Ballhead
Important! Always support the
camera with one hand when
loosening the tilt locking knob.
To adjust the tilt, loosen the ball
locking knob, and change the
position of the camera.
For 90° portrait orientation,
loosen the ball locking knob,
and place the ballhead into the
90° notch.
For 360° panning, loosen the
pan locking knob, and rotate
the base of the ballhead. Use
the degree scale at the base
of the head for precise aiming,
and tighten the locking knob
until secure.
Adjusting the
Center Column
To raise or lower the center
column, loosen the center-
column collar by turning it
counterclockwise.
Adjust the center column
to the desired height, and
tighten the center-column
collar until secure.
1
2
Product Specifications
| Brand: | Magnus |
| Category: | Tripod |
| Model: | TR-13 |
