Page 1/2
© Panduit Corp. 2023
INSTALLATION INSTRUCTIONS
For Technical Support: www.panduit.com/resources/install_maintain.asp
V00029TE
Page 1 of 8
FlexFusion Air Dam Seal Kits
Part Number(s) : XG-ADS6*, XG-ADS7*, & XG-ADS8*
Utility Knife
Tool List:
Air Dam
Seal Kit
Components Included
Top Horizontal Air Dam
Qty. 1
Bottom Horizontal Air Dam
Qty: 1
Finger Covers
Qty: 14 5RU covers &
10 8RU covers
Only included with part #
XG-ADS6*
1 X 7/8 Bulb Seal
Qty: 4
3/8 Bulb Seal
Qty: 2
1 Flap Seal
(1) Middle section
(2) 120mm End sections
1.75 Flap Seal
Qty: 1
M5x0.8 Hex Nut
Qty: 4
Locking Panel Plug
Qty: 2
Only included with part #s
XG-ADS7* & XG-ADS8*
© Panduit Corp. 2023
INSTALLATION INSTRUCTIONS
For Technical Support: www.panduit.com/resources/install_maintain.asp
V00029TE
Page 2 of 8
Attach (1) 3/8 Bulb Seal & (3) 1 Flap Seals to the Top Horizontal Air Dam
Install Top Horizontal Air Dam & secure with (2) M5x0.8 Hex Nuts
1
3/8 Bulb Seal
1 Flap Seal
(1) Middle section
(2) 120mm End sections
Section View
Install Top Horizontal Air Dam & Seals
2
(2) M5x0.8 Hex Nut
8mm Wrench
2 places - both ends
