Page 1/9
Product may vary slightly from the picture (RWV3CL9G pictured)
Issue 6
Description:
Model Numbers:
ROBINHOOD WALL CANOPY CURVED GLASS 60 and 90CM VETRO
RWV3CL6G, RWV3CL9G, RWV3CL60G, RWV3CL90G
Important Safety Instructions
Thank you for purchasing a quality Robinhood rangehood. Robinhood has a high standard of quality control and every
rangehood is tested and approved before it leaves the factory.
Important:
1. Please read the entire instructions before installing the rangehood, always switch power off prior to installation. All
electrical work must be done by a registered electrician in accordance with local and national electrical codes as
applicable. For your safety, this product must be earthed.
2. The power socket must be accessible and enable the end user to isolate the rangehood from the power for the
purpose of internal cleaning or maintenance.
3. A power outlet should be within 1500mm of the power cord exit from the rangehood.
4. The canopy hood is not intended for use by persons (including children) with reduced physical, sensory or metal
capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction concerning
use of the appliance by a person responsible for their safety
5. Children should be supervised to ensure that they do not play with the appliance.
6. There shall be adequate ventilation of the room when the rangehood is used at the same time as appliances
burning gas or other fuels.
7. There is a fire risk if cleaning is not carried out in accordance with the instructions. You must read the details concerning
the method and frequency of cleaning.
8. Do not flambé under the rangehood.
9. Exhaust air must not be discharged into an existing flue which is used for exhausting fumes from appliances
burning gas or other fuels.
10. The minimum distance between the hob surface and the lowest part of the rangehood is 600mm. This distance shall
be at least 650mm, if the rangehood is installed over a gas hob. If the instructions for the gas hob specify a greater
distance, this has to be taken into account.
11. Attention should be given to ensure that any applicable regulations concerning the discharge of exhaust air is
fulfilled. If re-circulating, ensure that the side outlet grilles on the upper chimney are not obstructed. Even a partial
obstruction will restrict the efficiency of the rangehood.
12. Stainless steel is very easily damaged during installation if abraded or knocked by tools. Protect the rangehood with
the cardboard box or plastic bag during installation.
13. Check the contents of the packaging, check all electrical functions of the canopy before installation. Canopy is
heavy. Please ensure adequate care when installing to prevent personal injury.
14. CAUTION: Accessible parts may become hot when used with cooking appliances
Pre-installation
RWV3CL6G, RWVCL60G RWV3CL9G, RWV3CL90G
• The canopy hood is designed for 2400mm-2700mm** ceilings.
• **For 2700mm ceiling height, the hood must be installed at 750mm above standard 900mm height
bench top
• The chimney is telescopic and is designed for hood installations between 650 to 750mm above the
cooking surface.
• Ascertain the desired installation height of the canopy hood.
• Any installation above 750mm will compromise the extraction performance.
• The air outlet from the motor requires 150mm round ducting
which requires 170mm diameter hole in the ceiling.
A=650mm(electric cook top) min
A=650mm(gas cook top) min
B=305mm
C=220mm
Product Specifications
| Brand: | Robinhood |
| Category: | Extractor hood |
| Model: | RWV 600 |
