Page 1/7
QUICK INSTALLATION
GUIDE
VULCAN
STANDARD
FN + F9 = Previous Track
FN + F10 = Stop
FN + F11 = Play/Pause
FN + F12 = Next Track
FN + Right Ctrl = Toggle LEDs On/Off
FN + Arrows Up/Down = LED Brightness Up/Down
FN + Arrows Left/Right = Cycle RGB effects
FN + Ins = Print Screen
FN + Home = Scroll Lock
FN + Page Up = Pause
FN + Del = Toggle change F9 – F12 secondary
and main functions
FN + End = Swap Win key and Fn key function
FN + Page Down = Toggle Game Mode
ADDITIONAL FN-LAYER FUNCTIONALITY (PRESS FN-KEY + SECOND KEY)
(no driver installed)
TECHNICAL FACTS
TECH SPECS VULCAN TKL
ROCCAT
®
Titan Switch Linear
1.4mm actuation point (red, linear)
50 million keystroke life-cycle
Compact TKL form factor
Detachable USB-C to USB-A cable
Integrated settings memory
ROCCAT
®
Easy-Shift[+] technology
32-bit ARM Cortex-M0 based processor
1,000Hz polling rate
ROCCAT
®
Swarm software suite
Weight:
660g
Dimensions:
360mm × 133mm × 34mm
Should you need assistance …
Our support team is ready to help you with any technical questions.
Just send an e-mail to support@roccat.com or visit our website at:
WWW.ROCCAT.COM/SUPPORT
SYSTEM REQUIREMENTS
Windows
®
7, 8 and 10 (software support)
USB 2.0 (or higher)
Internet connection (for driver software)
1. Til ergonomisk opstilling klappes fødderne på tastaturets
bund ud.
2. t ROCCAT Vulcan TKL’s USB-stik ind i en ledig USB-port
på din PC, og tilslut USB-C-stikket på bagsiden af din ROCCAT
Vulcan TKL.
3. Start computeren op, og forbind den med internettet.
4. Navigér til www.roccat.com/roccat-swarm, og download den
nyeste version af Swarm.
5. Start software-installationen, og følg anvisningerne på
skærmen.
INSTRUKTIONER
DK
1. For a more ergonomic position, fold out the stands on the base
of the keyboard.
2. Plug the ROCCAT Vulcan TKL’s USB connector into any free
USB port on your PC and the USB-C connector to the back of
the ROCCAT Vulcan TKL.
3. Start your computer and connect to the internet.
4. Navigate to www.roccat.com/roccat-swarm and download the
latest version of Swarm.
5. Start the software installation process and follow the on-
screen instructions
INSTRUCTIONS
EN
1. Para un equilibrio más ergomico, saca las patas que están
debajo del teclado.
2. Enchufa el conector USB del ROCCAT Vulcan TKL a un puerto
USB libre en tu PC y el conector USB-C en la parte posterior
del ROCCAT Vulcan TKL.
3. Inicie el ordenador y conéctese a internet.
4. Acceda a la página www.roccat.com/roccat-swarm y descár-
guese la última versión swarm.
5. Inicie el proceso de instalación de software y siga las instruc-
ciones de la pantalla.
INSTRUCCIONES
ES
تعليمات
ANLEITUNG
AR DE
1. للحصول على وضع أكثر راحة، قم بطي الحوامل الموجودة على قاعدة لوحة
المفاتيح.
2. قم بتوصيل موصل USB الخاص بـ ROCCAT Vulcan TKL بأي منفذ
USB غير مشغول في جهاز الكمبيوتر الشخصي وموصل USB-C بالجزء
الخلفي من ROCCAT Vulcan TKL
3. شغل جهازك وتأكد من توصيله بالأنترنت
4. افتح صفحة, وقم بتنزيل احداث اصدار من تطبيق سوارم الخاص
بروكات www.roccat.com/roccat-swarm
5. ابدأ بعملية تنزيل البرنامج واتبع التعليمات الظاهرة على الشاشة
1. Für einen ergonomischeren Stand klappe die Füße an der
Unterseite der Tastatur aus.
2. Schlie das USB-Kabel der ROCCAT Vulcan TKL an einen
beliebigen freien USB-Port an deinem PC an und stecke
den USB-C-Stecker in den Anschluss auf der Rückseite des
ROCCAT Vulcan TKL.
3. Starte deinen Computer und stelle eine Verbindung zum
Internet her.
4. Rufe www.roccat.com/roccat-swarm auf und lade dir die
neueste Swarm Version herunter.
5. Starte die Software-Installation und folge den Anweisungen.
1. plie les pieds sur la face inrieure du clavier pour une plus
grande ergonomie.
2. Branchez l’embout USB du ROCCAT Vulcan TKL dans n’im-
porte quel port USB de votre PC et l’embout USB-C à l’arrière
du ROCCAT Vulcan TKL.
3. Allumez votre PC et connectez-vous à internet.
4. Allez sur www.roccat.com/roccat-swarm et téchargez la
dernière version de Swarm.
5. Débutez l’installation du programme et suivez les indications.
INSTRUCTIONS
FR
OHJEET
FI
1. Käännä näppäimistön alla olevat jalat ulos ergonomista
asentoa varten.
2. Yhdistä ROCCAT Vulcan TKL:n USB-liitin mihin tahansa
tietokoneesi vapaista USB-porteista ja USB-C-liitin ROCCAT
Vulcan TKL:n takaosaan.
3. Käynnistä tietokoneesi ja yhdistä internetiin.
4. Siirry osoitteeseen www.roccat.com/roccat-swarm ja lataa
Swarm-ohjelmiston uusin versio.
5. Käynnistä ohjelmiston asennusprosessi ja seuraa näyttöruud-
ulla näkyviä ohjeita.
1. キーボド底面のスドを立てと人間工学的によよいポジシ
ンで使用できます
2. ROCCAT Vulcan TKLUSB 、ご PCいて
USBポート USB-CネクタROCCAT Vulcan TKL
してく
3. コンピュータ動し、インタートに接続します
4. www.roccat.com/roccat-swarm ート
し、Swarm の最新バージョンをダウンロードします
5. ソフトウェアンストール います。
使用説明
JP
