Read below 📖 the manual in Italian for Simrad SonarHub (1 pages) in the Not categorized category. This guide has been helpful for 21 people and has been rated 4.5 stars on average by 2 users

Page 1/1
204 mm (8.03")
169 mm (6.63")
TRANSDUCER1 TRANSDUCER2
NET-3NET-1POWER
12V/24V 3A
NET-2
91 mm
(3.58")
180 mm
57 mm (2.24")
207 mm
183 mm (7.20")
Dimensions
MountingParts included
ID DESCRIPTION
000-11142-001
SonarHub only
000-11141-001
SonarHub w/
LSS HD XDCR
000-11300-001
SonarHub w/
TM150 XDCR
000-11301-001
SonarHub w/
LSS TM150 and
LSS HD XDCRs
000-11304-001
SonarHub w/
SPOTLIGHT
XDCR
1SonarHub module 1 1 1 1 1
2SonarHub installation screws 4 4 4 4 4
3Ethernet cable, 4 m (15 ft) 1 1 1 1 1
4Power cable, 2 m (6.6 ft) 1 1 1 1 1
5Fuse and Fuse holder 1 1 1 1 1
6LSS StructureScan HD XDCR 1 1
7TM150 CHIRP XDCR 1 1
8SPOTLIGHT Heading sensor 1
9Trolling Motor clamp 1
10 SPOTLIGHT XDCR 1
1
2
3
4
6
5
7
8
9
10
SonarHub
Installation Guide
For technical specifications, certificates and
declarations, refer to the product web site
on:
*988-10539-001*
simrad-yachting.com
lowrance.com
TRANSDUCER1 TRANSDUCER2
NET-3NET-1POWER
12V/24V 3A
NET-2
TRANSDUCER1 TRANSDUCER2
NET-3NET-1POWER
12V/24V 3A NET-2
TRANSDUCER1 TRANSDUCER2
NET-3NET-1POWER
12V/24V 3A
NET-2
TRANSDUCER1 TRANSDUCER2
NET-3NET-1POWER
12V/24V 3A
NET-2
