Page 1/48
© 2019 Sony Corporation
ENG Style Buildup Kit
Operating Instructions
CBK-FS7BK
Extension Unit Software Version 2.0
Network Module Software Version 3.46
5-010-028-12 (1)
GB
0002
1. Overview
Features ..............................................................................3
Location and Function of Parts ..........................................4
2. Device Setup
Attaching the Shoulder Plate ............................................7
Attaching the Handle Adapter and Top Plate ................... 8
Attaching the Viewfinder ..................................................9
Attaching the Extension Unit ...........................................10
Attaching a Portable Wireless Tuner (when using a
wireless microphone) ..............................................12
3. Device Adjustment and Setup
Adjusting the Viewfinder .................................................13
Adjusting the Shoulder Pad .............................................16
4. Network Function Setup
Compatible Terminal Devices and Functions ..................17
Turning On the Network Module ....................................18
Setting the Camcorder ..................................................... 19
Connecting to a Terminal Device via Wireless LAN ........20
Connecting to the Internet ..............................................22
5. Network Function Operations
Recording the Video of a Camcorder ...............................24
Uploading a File ...............................................................27
Streaming Live Video from the Camcorder .....................28
Controlling the Camcorder Remotely ..............................29
6. Network Function Setup Using the Web Menu
Web Menu .......................................................................30
Streaming Format Settings ..............................................32
Proxy Format Settings ......................................................34
System Settings ...............................................................35
Access Point Settings (AP Settings) ................................37
Wireless LAN settings (Station Settings) ........................38
Modem Settings ...............................................................39
Wired LAN Settings ..........................................................40
Upload Settings ................................................................41
Checking File Uploading (Job List) ..................................43
7. Maintenance
Updating the Unit ............................................................44
8. Appendix
Usage Precautions ............................................................45
Troubleshooting ...............................................................46
Error/Warning Indications ............................................... 47
Licenses ............................................................................ 48
Specifications ...................................................................51
Table of Contents
0003
1. Overview
Features
The CBK-FS7BK is an accessory kit that attaches
to a PXW-FS7-series camcorder to provide the
stability and operability of the camcorder when
used shoulder camcorder style. In addition to
the XDCA-FS7 functionality, it features a robust
viewfinder, sliding shoulder plate, wireless
audio receiver slot, and comprehensive network
functions. FS7-series camcorders can also be
operated with a B4 lens by attaching the LA-EB1
(option).
Remote Operation of Camcorder via a
Wireless LAN
When the unit is connected to a PXW-FS7-series
camcorder (hereinafter, “camcorder”) by USB cable,
you can operate the camcorder remotely from a
smartphone/tablet/computer that is connected
via wireless LAN.
Creating and Recording a Proxy File
The unit creates a proxy file (low resolution) and
records it on an SD card that is inserted into the
unit, from the HD-SDI input video and audio
signals that are shot or played on the camcorder.
The created file is called “XAVC (R) Proxy.”
Recording starts/stops automatically in lock with
the camcorder Rec/Stop control signals that are
embedded in the HD-SDI signal.
When recording using the camcorder, you
can create a proxy file of the same duration
that inherits the information of the original file
recorded on the camcorder.
Uploading a File via a 3G/4G/LTE
Network, Wireless LAN, or Wired LAN
You can upload a proxy file (low resolution) that
is recorded on an SD card in the unit to a server
on the Internet via a 3G/4G/LTE network, wireless
LAN, or wired LAN.
Monitoring Camcorder video via a
Wireless LAN
The unit can create a stream (H.264) from the
camcorder video, which can be monitored using
the “Content Browser Mobile” application on a
smartphone/tablet via wireless LAN.
“Content Browser Mobile”
Application*
You can configure the settings of the unit from a
smartphone/tablet using the “Content Browser
Mobile” application.
* For details about the “Content Browser Mobile”
application, contact your Sony dealer or a Sony service
representative.
Streaming Camcorder Video/Audio
via a 3G/4G/LTE Network, Wireless
LAN, or Wired LAN
The unit can create a stream (H.264/AAC-LC
compression) from the camcorder video/audio,
which can be streamed via a 3G/4G/LTE network,
wireless LAN, or wired LAN.
[Note]
If you start streaming, proxy recording and file transfer
cannot be performed.
High Quality Streaming using Sony’s
QoS Technology
When connected to a Connection Control
Manager (CCM) of a Sony Network RX Station
(option) or XDCAM air*, the unit supports high
quality streaming and file uploading via the CCM.
* XDCAM air is a cloud service that is provided by Sony. To
use this service, registration is required.
XDCAM air is not provided in some regions. For details on
areas where the service is provided, refer to the following
site.
https://www.xdcam-air.com
For more details, contact a Sony professional sales
representative.
In addition, refer to the following sites for the privacy
policy of XDCAM air.
Terms of service
https://www.xdcam-air.com/site/tos_eu.html
Privacy policy of XDCAM air
https://sony-imaging-products-solutions.co.jp/pp/sips/
en/index.html
Privacy policy of professional ID
https://www.pro-id.sony.net/#/privacyPolicy
[Notes]
The unit works in combination with the latest version of
the Network RX Station.
If network client mode for streaming with Sony’s QoS
Technology is set to on with proxy recording enabled,
the streaming bit rate is limited by the proxy recording
setting. File uploading stops when streaming is started.
You can change the proxy recording setting by operating
the CCM.
You can perform stable streaming with high picture
quality using multiple networks. (Depending on the
scene, the target bit rate may be exceeded.)
This function is available when [Proxy Recording] is set to
“Off” or when [Proxy Recording] cannot be set.
Use separate network connections to acquire stable
performance.
To use this function, contact your Sony professional sales
representative.
