INSTRUCTION MANUAL
LED LINEAR LIGHT - SURFACE
TECHNICAL DATA
SKU
MODEL VT-7-46
40W
3400
120°
0.9
AC: 200-240V, 50Hz
1200x50x65mm
POWER
LUMENS
BEAM ANGLE
DF
INPUT POWER
DIMENSION
20462, 20463, 20464
20466, 20467, 21463
INTRODUCTION
Thank you for selecting and buying V-TAC product. V-TAC will serve you the best. Please read these instructions
carefully before starting the installation and keep this manual handy for future reference. If you have any another
query, please contact our dealer or local vendor from whom you have purchased the product. They are trained
and ready to serve you at the best.
WARNING
1. Please make sure to turn o the power before starting the installation.
2. Installation must be performed by a qualified electrician.
3. Proper grounding should be ensured throughout the installation.
4. The light source of this luminaire is not replaceable; when the light source reaches its end of life the whole
luminaire shall be replaced.
5. For Indoor use only
6. Before installation, you must carefully check the integrity of the product and accessories
7. When installed, products and flammable materials to ensure that at least 0.2m distance, lighting cannot be
installed in the zenith or heat wall, pay attention to low voltage and high voltage electrical wiring separately.
8. To ensure that the power cord has enough length, do not kink cables. Output cables should be laid separately
and at a distance from other cables.
This marking indicates that this
product should not be disposed
of with other household wastes.
Caution, risk of electric shock.
INSTALLATION DIAGRAM
INSTALLATION INSTRUCTIONS
WIRING DIAGRAM
• Switch o the power before starting the installation.
• Open end cap from any 1 side of the diuser, slide the diuser into the fitting. Close the end cap
by using screws. (Figure 1)
• Choose the right position and drill 2 holes on the mounting surface. Then fix the brackets onto
the mounting surface with help of expansion screws. (Figure 2 & 3)
• Connect the wiring as per the wiring diagram, then install the light onto the bracket. (Figure 4).
• Switch on the power and test.
IN CASE OF ANY QUERY/ISSUE WITH THE PRODUCT PLEASE REACH OUT TO US AT
SUPPORT@VTACEXPORTS.COM V-TAC HOUSE, KELPATRICK ROAD, SLOUGH, BERKSHIRE, SL1 6BW, UK.
