Page 1/8

Before using the appliance carefully read Safety Instructions.

APPLIANCE

PRODUCT DESCRIPTION

THANK YOU FOR BUYING A WHIRLPOOL PRODUCT. In

order to receive a more complete assistance, please regi-

ster your appliance on: www.whirlpool.eu/register

You can download the Safety Instructions and the User

Manual, by visiting our website docs.whirlpool.eu/docs

and following the Instructions on the back of this

booklet.

7 11 12

1. On-O/Reset button with indicator light

2. Program selection button with indicator light

3. Multizone button with indicator light / Keylock

4. Eco program indicator light

5. Keylock indicator light

6. Display

7. Program number and remaining time indicator

DAILY REFERENCE

GUIDE

CONTROL PANEL

8. Tablet (Tab) indicator light

9. Closed water tap indicator light

10. Rinse Aid rell indicator light

11. Salt rell indicator light

12. Power Clean® button with indicator light / Tablet (Tab)

13. Delay button with indicator light

14. Start/Pause button with indicator light / Drain out

0000 000 00000

Service:

1. Upper rack

2. Foldable aps

3. Upper rack height adjuster

4. Upper spray arm

5. Lower rack

6. Power Clean® support

7. Cutlery basket

8. Lower spray arm

9. Filter Assembly

10. Salt reservoir

11. Detergent and Rinse Aid dispensers

12. Rating plate

13. Control panel

FIRST TIME USE

SALT, RINSE AID AND DETERGENT

ADVICE REGARDING THE FIRST TIME USE

After installation, remove the stoppers from the racks and the retaining

elastic elements from the upper rack.

FILLING THE SALT RESERVOIR

The use of salt prevents the formation of LIMESCALE on the dishes

and on the machine’s functional components.

• It is mandatory that THE SALT RESERVOIR NEVER BE EMPTY.

• It is important to set the water hardness.

The salt reservoir is located in the lower part of the dishwasher

(see PRODUCT DESCRIPTION) and must be lled when the SALT REFILL

indicator light in the control panel is lit.

1. Remove the lower rack and unscrew the

reservoir cap (anticlockwise).

2. Only the rst time you do this: ll the salt

reservoir with water.

3. Position the funnel (see gure) and ll the salt

reservoir right up to its edge (approximately 1

kg); it is not unusual for a little water to leak out.

4. Remove the funnel and wipe any salt residue

away from the opening.

Make sure the cap is screwed on tightly, so that no detergent can get

into the container during the wash program (this could damage the wa-

ter softener beyond repair).

Whenever you need to add salt, it is mandatory to complete the pro-

cedure before the beginning of the washing cycle to avoid corrosion.

SETTING THE WATER HARDNESS

To allow the water softener to work in a perfect way, it is essential that

the water hardness setting is based on the actual water hardness in your

house. This information can be obtained from your local water supplier.

The factory sets the default value for the water hardness.

• Switch on the appliance by pressing the ON/OFF button.

• Switch o the appliance by pressing the ON/OFF button.

• Hold down button START/Pause for 5 seconds, until you hear a beep.

• Switch on the appliance by pressing the ON/OFF button.

• The current selection level number and the salt indicator light both ash.

• Press button P to select the desired hardness level (see WATER HARD-

NESS TABLE).

• Switch o the appliance by pressing the ON/OFF button.

Setting is complete!

As soon as this procedure is complete, run a program without loading.

Only use salt that has been specically designed for dishwashers.

After the salt has been poured into the machine, the SALT REFILL indi-

cator light switches o.

If the salt container is not lled, the water softener and the heating

element may be damaged as a result of limescale accumulation.

Using of Salt is recommended with any type of dishwasher detergent.

Water Hardness Table

Level

°dH

German degrees

°fH

French degrees

°Clark

English degrees

1 Soft 0 - 6 0 - 10 0 - 7

2 Medium 7 - 11 11 - 20 8 - 14

3 Average 12 - 16 21 - 29 15 - 20

4 Hard 17 - 34 30 - 60 21 - 42

5 Very hard 35 - 50 61 - 90 43 - 62

FILLING THE RINSE AID DISPENSER

Rinse aid makes dish DRYING easier. The rinse aid dispenser A should be

lled when the RINSE AID REFILL indicator light in the control

panel is lit.

1. Open the dispenser B by pressing and pulling up the tab on the lid.

2. Pour in the rinse aid (max.110 ml), making sure it does not overow

from the dispenser. If this happens, clean the spill immediately with

a dry cloth.

3. Press the lid down until you hear a click to close it.

NEVER pour the rinse aid directly into the appliance tub.

ADJUSTING THE DOSAGE OF RINSE AID

If you are not completely satised with the drying results, you can ad-

just the quantity of rinse aid used.

• Switch the dishwasher on using the ON/OFF button.

• Switch it o using the ON/OFF button.

• Press button START/Pause three times - a beep will be heard.

• Switch it on using the ON/OFF button.

• The current selection level number and rinse aid indicator light ash.

• Press button P to select the level of rinse aid quantity to be supplied.

• Switch it o using the ON/OFF button

Setting is complete!

If the rinse aid level is set to 1 (ECO), no rinse aid will be supplied. The

LOW RINSE AID indicator light will not be lit if you run out of rinse aid.

A maximum of 5 levels can be set according to the dishwasher model.

The factory setting is specic to the model, please follow instruction

above to check this for your machine.

• If you see bluish streaks on the dishes, set a low number (2-3).

• If there are drops of water or limescale marks on the dishes, set a mid-

-range number (4-5).

FILLING THE DETERGENT DISPENSER

To open the detergent dispenser use the opening device C. Intro-

duce the detergent into the dry dispenser D only. Place the amount

of detergent for pre-washing directly inside the tub.

1. When measuring out the detergent

refer to the mentioned earlier infor-

mation to add the proper quantity.

Inside the dispenser D there are indi-

cations to help the detergent dosing.

2. Remove detergent residues from

the edges of the dispenser and clo-

se the cover until it clicks.

3. Close the lid of the detergent dispen-

ser by pulling it up until the closing

device is secured in place.

The detergent dispenser automatically opens up at the right time

according to the program.

If all-in-one detergents are used, we recommend using the TABLET

button, because it adjusts the program so that the best washing

and drying results are always achieved.

Usage of detergent not designed for dishwashers may cause mal-

function or damage to the appliance.

PROGRAMS TABLE

PROGRAMS DESCRIPTION

ECO program data is measured under laboratory conditions according to European Standard EN 60436:2020.

Note for Test Laboratories:

For information on comparative EN testing conditions, please send an email to the following address: dw_test_support@europeanappliances.com

Pre-treatment of the dishes is not needed before any of the programs.

*) Not all options can be used simultaneously.

**) Values given for programs other than the program Eco are indicative only. The actual time may vary depending on many factors such as temperature

and pressure of the incoming water, room temperature, amount of detergent, quantity and type of load, load balancing, additional selected options

and sensor calibration. The sensor calibration can increase program duration up to 20 min.

Program

Drying

phase

NaturalDry

Available

options

Duration

of wash

program

(h:min)

**)

Water con-

sumption

(litres/cycle)

Energy con-

sumption

(kWh/cycle)

1 Eco 50°

3:10 9.5 0.85

2 6

Sense®

50-60°

1:25 - 3:00 7.0 - 14.0 0.90 - 1.40

3 Intensive 65°

2:50 14.0 1.50

4 Fast Wash&Dry 50°

1:25 11.5 1.10

5 Crystals

45°

1:40 11.5 1.20

6 Rapid 30’ 50°

0:30 9.0 0.50

7 Silent 50°

3:30 15.0 1.15

8 Pre-Wash -

0:12 4.5 0.01

Instructions on wash cycle selection.

1 ECO

Eco programme is suitable to clean normally soiled tableware, that

for this use, it is the most ecient programme in terms of its combined

energy and water consumption, and that it is used to assess compliance

with the EU Ecodesign legislation.

2 6

SENSE®

For normally soiled dishes with dried food residues. Senses the level

of soiling on the dishes and adjusts the program accordingly. When

the sensor is detecting the soil level an animation appears in the display

and the cycle duration is updated.

3 INTENSIVE

Program recommended for heavily soiled crockery, especially suitable

for pans and saucepans (not to be used for delicate items).

4 FAST WASH&DRY

Normally soiled crockery. Everyday cycle, that ensures optimal cleaning

performance in shorter time.

5 CRYSTALS

Program for delicate items, which are more sensitive to high

temperatures,

for example glasses and cups.

6 RAPID 30’

Program to be used for half load of lightly-soiled dishes with no dried

food residues. Does not have drying phase.

7 SILENT

Suitable for night-time operation of the appliance. Ensures optimal

cleaning and drying performance with the lowest noise emission.

8 PRE-WASH

Use to refresh crockery planned to be washed later. No detergent to be

used with this program.

Notes:

Please note that cycle Rapid 30’ is dedicated for lightly soiled dishes.
