AEG AAF7B Manual
AEG
Deep fryer
AAF7B
Read below 📖 the manual in Italian for AEG AAF7B (57 pages) in the Deep fryer category. This guide has been helpful for 24 people and has been rated 4.5 stars on average by 2 users
Page 1/57
Air Fryer
Instruction Book
AAF3B, AAF5B, AAF7B
General Overview Before first use
1. Remove all the packaging and protective material.
2. Clean the basket and pan with warm water and dish soap. Wipe inside and outside of the
appliance with a soft cloth.
3. It is normal for a new unit to emit odors the f irst few times it is operated.
Run the empty air fryer at 200°C for 20 minutes before f irst use to avoid that.
2
3
How to use
2
1
3
1. Place the appliance on a flat, stable and “heat-resistant” surface.
2. Pull out the pan and place it on a stable surface.
3. Put the food in the basket, observing the “MAX”. capacity indication.
20min
200˚C
START
Accessories may very from model to model
A
B
C
Pan
Basket
Basket handle
D
E
Basket release
button
Control panel
F
G
MultiCoaster
Air inlet
H
I
Air outlet
Main cord
E F
B C DA
1
3
2
5
4 8
7
6
9
12 13 14 15 16
10
11
1
2
3
4
On/Of f
Play/Pause
Temperature
control
Temperature
indicator (60-200˚C)
5
6
7
8
Time control
Time indicator
(0-99 min.)
Shake Reminder
Heating-up
indicator
9
10
11
12
Air Fry function
Bake function
Reheat function
French Fries/
Frozen snacks
13
14
15
16
Vegetables
Chicken
Steak
Fish
EN
CA
BG
NL
FR
DE
GR
IT
ES
PT
EN
CA
BG
NL
FR
DE
GR
IT
ES
PT
1
H
G
I
10
10. Depending on the type of ingredient, flip the food mid-cooking or every 7 minutes by using
a heat-resistant tool or by just carefully shaking the food inside the basket. (see Cooking Guide).
CAUTION: Be careful not to press the ”Basket Release Button” when shaking the food.
CAUTION: Be careful with hot surfaces when the appliance is in use.
5. Plug in the appliance.
6. Press the On/O button.
7. Select the desired cooking method. For example, Air Fry function.
8. Adjust the time and temperature to your taste or select one of the pre-set recipes.
For example, French Fries.
9. Press the Play/ Pause button.
6
5
7
4
4. Push the pan with food completely back into the appliance.
CAUTION: Do not use the appliance without the basket.
11. At the end of the cooking time, the appliance will issue a beep signal.
12. Carefully remove the pan and place it on a heat-resistant surface.
13. To remove the basket from the pan, follow these instructions:
- Slide the transparent button cover
- Press the "Basket Release Button"
- Lift the basket from the pan
CAUTION: Hot steam can come out of the basket when it is opened mid or at the end of cooking.
Make sure your face, arms and hands are away from the steam when opening it.
12
11
8
9
13
14. Unplug the appliance after using it.
15.
The versatile MultiCoaster fits on top of the
air fryer as a space-saving hotplate for the
cooking basket or resting place for tools and
spices when cooking. It’s also removable to use
at the table when serving food from the
hot basket.*
* Accessories may very from model to model.
NOTE: Be careful with oil to avoid stains on the cork
material.
14
15
Heating-up indicator
The ”Heating-up indicator” is activated when the ”Bake function” is
selected, and it works as a pre-heat function so that the air fryer has
the ideal temperature before cooking your favorite baked recipes.
The timer only starts to count down once the pre-heating has finished.
If wished, you can skip the pre-heating step by tapping the ”Play/
Pause” button. The display will then show the target temperature,
while the ”Heating up indicator” icon will turn o and the timer will
start to count down.
Shake Reminder
The ”Shake Reminder” is activated during the pre-sets of some
recipes, such as French Fries/Frozen Snacks, Vegetables and Chicken.
When it is time to shake or flip your food, the ”Shake Reminder” icon
will light up and blink for one minute, while a beep sound will repeat for
three times.
The ”Shake Reminder” is not mandatory, hence the cooking will
continue as usual even if the food is not flipped or shaken.
Heating-up indicator
Shake Reminder
EN
CA
BG
NL
FR
DE
GR
IT
ES
PT
EN
CA
BG
NL
FR
DE
GR
IT
ES
PT
Product Specifications
| Brand: | AEG |
| Category: | Deep fryer |
| Model: | AAF7B |
