Page 1/8
DANGER
WARNING
CAUTION
NOTICE
Important Safety Messages
Read the instructions carefully and look at the equipment to become familiar with the device before trying to install,
operate, service or maintain it. The following special messages may appear throughout this document or on the
equipment to warn of potential hazards or to call attention to information that claries or simplies a procedure.
The addition of this symbol to a Danger or Warning product safety label indicates that an electrical hazard exists
that will result in personal injury if the instructions are not followed.
User Manual Easy UPS
SNMP Card APVS9602
The addition of this symbol to either a “Danger” or “Warning” safety label indicates that an
electrical hazard exists which will result in personal injury if the instructions are not followed.
This is the safety alert symbol. It is used to alert you to potential personal injury hazards. Obey all
safety messages that follow this symbol to avoid possible injury or death.
DANGER indicates a hazardous situation which, if not avoided, will result in death or serious
injury.
WARNING indicates a hazardous situation which, if not avoided, could result in death or serious
injury.
CAUTION indicates a hazardous situation which, if not avoided, could result in minor or moderate
injury.
NOTICE is used to address practices not related to physical injury.
2 SNMP Card APVS 9602
Product Description
Integrated with Easy UPS LI SNMP Manager software, devices with the SNMP Card installed can be
monitored and controlled in LAN.
APVS 02 SNMP Card: 96
Provides SNMP MIB to monitor & control UPS.
Auto-senses 10M /100M/1000M Fast Ethernet Manage and congure via Web Browser or NMS.
Supports TCP/IP, UDP, SNMP, HTTPS, SMTP, FTPS Protocols.
Supports SSL/TLS Encryptions.
Provides easy setup and upgrade tools via Easy UPS LI SNMP Manager software.
Sends SNMP TRAP; E-mail for events notication.
Emails daily UPS history report.
Performs graceful shutdown via Easy UPS LI Shutdown software.
Devices in which you can install the SNMP Card
The SNMP Card can be installed in any compatible device that has an Intelligent Card Slot, including:
Easy UPS: SMVS series UPS
Package Contents
The packaging is recyclable; save it for reuse or dispose of it properly.
(1)
SNMP Card
(1)
User manual
(1)
Utility CD
Disclaimer
Schneider Electric is not responsible for damage sustained during reshipment of this product.
The SNMP Card is sensitive to static electricity. When handling the SNMP Card, touch only
the end plate while using one or more of these electrostatic-discharge devices (ESDs): wrist
straps, heel straps, toe straps, or conductive shoes.
SNMP Card APVS9602 3
Product Overview
Front Panel
●
1
10/100 Base-T connector
Connects SNMP card to the Ethernet network.
●
2
Status LED
See “Status LED”.
Status LED
Color LED
Condition
Description
100M LED (Green)
Flash
Port is operating at 100Mbit/s
Off
Card is not connected to the network
10M LED (Yellow)
Flash
Port is operating at 10Mbit/s
Off
Card is not connected to the network
LED(Red)
Flash
Lost UPS connection
Off
Connecting with UPS
LED(Yellow)
On
SNMP card is operating
Off
SNMP card stop working
Note:
The port is operating at 1000Mbit/s when both Green(100M) and Yellow(10M) LED illuminating.
DO NOT turn o power when updating rmware. LED (red) will keep ashing.
Product Specifications
| Brand: | Apc |
| Category: | Network card/adapter |
| Model: | APVS9602 |
