Page 1/2
Intgergrate and maximise your Solar PV with
in-built timer controlled heat up cycles.
Non-sacrificial impressed current anode provides
protection in soft and hard water conditions.
Hybrid technology with four unique heating
modes, to match household demand.
Registered Clean Energy product with annual
carbon reduction rating of 3 tonnes.
6 YEAR
MAX COP
4.90
PEOPLE
24-31
STCS
210 L
TANK CAPACITY
70°C
MAX TEMP.
350% efficiency rating reduces annual running
costs versus gas and electric water heaters.
N
A
T
U
R
A
L
R
E
F
R
I
G
E
R
A
N
T
R290 natural refrigerant with effectively zero
global warming potential compared to synthetic
www.aquatechheatpumps.com.au
Federal & State
rebates available
RAPID/X6
SPECIFICATION SHEET
Compact size that fits the same install footprint as
an electric 250L, for quick and easy upgrading.
1300 769 904
RAPID/X6
SPECIFICATION SHEET
Continuous Tariff
Aquatech systems comes back with a 5
year replacement warranty, which covers
all system components including the tank
and compressor. If the system should
experience an unrepairable fault within the
warranty period, we will provide a free
replacement system.
Zone 1 = 25 STCs
Zone 2 = 23 STCs
Zone 3 = 29 STCs
Zone 4 = 31 STCs
Zone 5 = 31 STCs
The Hydrotherm Range is certified for compliance to the following Australian Standards for construction &
performance. AS 2712:2007 Solar & Heat Pump Design | AS 3498: 2009 Legionella Control | AS 60335.240
Electrical Safety AS 4020 Potable Water Quality | AS 5125 Heat Pump Performance Test | AS 4692 Tank Heat
Loss Test Engineered by: Aquatech Solar Technologies Pty Ltd | ABN 68 136 584 328
Shoulder Tariff
Solar PV/Timers
SYSTEM CAPACITYSTC VALUES
INSTALLATION PARAMETERS
HEATING PARAMETERS
*260L with 40°C water temprerature rise at 19°C air temperature
Operating Modes
Max. Temp. Heat pump
Max Temp. Element
Tank Recovery
(heat pump)
COP
(heat pump)
Heating capacity
(heat pump)
Eco, Standard, Hybrid, Hybrid+
60°C
70°C
225 minutes*
4.25*
2.65kW*
TECHNICAL SPECIFICATIONS
Electricity Supply
Circuit
Power Connection
Tariff Connection
Compressor Rating
Element Rating
Protection Class
Refrigerant
Tank Material
Tank Storage Capacity
Condensate Connection
Water Connections
PTR Rating
ECV Rating
Pressure Reduction Valve
Tempering Valve
System Weight
System Dimensions
Packed Weight
Packed Dimensions
Minimum Base Size
220-240 V/50-60 Hz
10 Amp/Single Phase
Hardwired/Isolated
Continuous/Shoulder/TOU
700-900W
1800W
IPX4
R290 (350g)
Vitreous Enamel
210 L
1/2”Elbow
(supplied)
3/4”G
850 kPa
(supplied)
700 kPa
(suggested)
500 kPa
(max.)
High Performance
(suggested)
108kg
620 mm x 1582 mm
125 k g
700 mm x 700 mm x
1750 mm
600 mm x 600 mm
600mm
150mm
wall
STRUCTURE
600mm150mm
300mm
1300 769 904
www.aquatechheatpumps.com.au
