YR SERIES ICEMAKER END-USER MANUAL
In order to provide the best
service, Atosa requests that
you register your warranty at
www.atosausa.com
For any service issues, please
contact us at:
Email: service@atosausa.com
or call us Toll Free:
1-855-855-0399
Please clean the filter frequently
DO NOT OVERLOAD
Please clean the filter frequently
DO NOT OVERLOAD
YR140-AP-161 / YR280-AP-161 / YR450-AP-161 / YR800-AP-161
1 / 22
Content
I.
Summary ................................................................................................................................... 2
1. Model ................................................................................................................................ 2
2. Ice production ................................................................................................................... 3
II.
Safety Notices............................................................................................................................ 4
III.
Installation ............................................................................................................................. 5
1. Power supply ..................................................................................................................... 5
2. Construction ...................................................................................................................... 6
3. Accessories ........................................................................................................................ 7
4. Ice bin installation ............................................................................................................. 7
5. Ice machine head installation ........................................................................................... 7
6. Obstruction panel installation（no in the self-contained machine） ........................... 8
7. Connect the water inlet hose and drain hose ................................................................... 8
8. Installation location ........................................................................................................... 9
IV.
Operation ............................................................................................................................ 10
1. Checklist before operation .............................................................................................. 10
2. operation ......................................................................................................................... 10
3. Ice weight per batch ........................................................................................................ 11
V.
Maintenance ........................................................................................................................... 12
Clean and sanitize ........................................................................................................................... 12
Condenser air-filter wash ........................................................................................................ 15
VI.
Service ................................................................................................................................. 16
1. Diagram ........................................................................................................................... 17
2. Safety protection ............................................................................................................. 17
3. LED indication .................................................................................................................. 17
4. Failures analysis ............................................................................................................... 18
5. Customer Support ........................................................................................................... 19
6. Waste disposal ................................................................................................................ 20
7. Commercial Ice Machine Warranty ................................................................................. 20
2 / 22
I.
Summary
The following data are for reference only
1.
Model
Model
YR140-AP-161
YR280-AP-161
YR450-AP-161
YR800-AP-261
Cooling style
Air
Air
Air
Air
Power supply
110-120V/
60Hz
110-120V/
60Hz
110-120V
/60Hz
220-240V
/60Hz
Power(W)
363
704
965
1700
Max Ice
production(IBS/24hr)
140lb
280lb
450lb
800lb
Dimension(mm)
601*725*981
601*725*981
765*610*557
765*610*801
Weight(kg)
65
70
57
90
Refrigerant
R290/90g
R290/90g
R290/150g
R404a/440g
Using temp. range
2～43℃
2～43℃
2～43℃
2～43℃
Water temp. range
1～32℃
1～32℃
1～32℃
1～32℃
Water pressure range
15～90Psi
15～90Psi
15～90Psi
15～90Psi
Power range
+10%/-15%
+10%/-15%
+10%/-15%
+10%/-15%
