Page 1/12
[ 1 ]
Bitspower Nebula VGA Water Block for ASUS ROG
Strix and TUF Gaming GeForce RTX 4080 series
V1
1
GPU
(Not included)
Step 1 Step 2
Step 4Step 3
1
2
3
Back plate
M2.5 x 8 Screw
1
BP-VG4080AST 1 SET
1 PC
11 PCS
1
Two screws fastened in advance.
2
2
3
3
[ 2 ]
Step 5
motherboard
DRGB Multi Function Controller
(Not included)
BPTA-DRGBMFC
1
2
In
Out
Digital RGB PIN on
1
motherboard or
2
other equipment.
Original I/O shield
(Not included)
Original Screw
(Not included)
1
2
3
Back plate
M2.5 x 8 Screw
1
BP-VG4080AST 1 SET
1 PC
11 PCS
1
Two screws fastened in advance.
[ 3 ]
Make sure the correct thermal pads are in the appropriate locations.
Use an appropriate amount of thermal paste.
1.0 mm Thermal pad
Name
Thermalpad1
Thermalpad2
Thermalpad3
Thermalp
Thermalpad5
Thermalpad6
Specification Quantity
8×12×1mm
13×16×1mm
15×37×1mm
6×52×1mm
12×52×1mm
10
4
4
3
2
2
1.5 mm Thermal pad
Thermalp
Thermalp
1
2
ad 8
ad 7
93.8×19.5×1.5mm
30×19.5×1.5mm
1
1 1
1
1
1
1
1
1
1
5
5
6
6
3
3
2
2
6
6
5
5
9
9
9
7 78
2.5 mm Thermal pad
ad 9
8×12×2.5mm
