Read below 📖 the manual in Italian for Cameo Steam Wizard 2000 (30 pages) in the Effect machine category. This guide has been helpful for 25 people and has been rated 4.5 stars on average by 2 users
Page 1/30
STEAM WIZARD 1000/2000
LED FOG MACHINE
CLSW1000
CLSW2000
USER´S MANUAL
BEDIENUNGSANLEITUNG
MANUEL D`UTILISATION
MANUAL DE USUARIO
INSTRUKCJA OBSŁUGI
MANUALE D‘ USO
ITALIANOPOLSKIESPAÑOL
FRANCAISDEUTSCHENGLISH
3
DMX
CONTENTS / INHALTSVERZEICHNIS / CONTENU / CONTENIDO / TREŚĆ / CONTENUTO
ENGLISH
PREVENTIVE MEASURES 3-4
INTRODUCTION 4
CONNECTIONS, OPERATING AND DISPLAY ELEMENTS 5
OPERATION 6
CABLE REMOTE CONTROL 6-7
INSTALLATION AND ASSEMBLY 7-8
DMX TECHNOLOGY 9
TECHNICAL DATA 10
MANUFACTURER´S DECLARATIONS 10
DMX CONTROL 55
DEUTSCH
SICHERHEITSHINWEISE 11-12
EINFÜHRUNG 12
ANSCHLÜSSE, BEDIEN- UND ANZEIGEELEMENTE 13
BEDIENUNG 14
KABEL-FERNBEDIENUNG 14-15
AUFSTELLUNG UND MONTAGE 15-16
DMX TECHNIK 17
TECHNISCHE DATEN 18
HERSTELLERERKLÄRUNGEN 18
DMX STEUERUNG 55
FRANCAIS
MESURES PRÉVENTIVES 19-20
INTRODUCTION 21
RACCORDEMENTS, ÉLÉMENTS DE COMMANDE ET D’AFFICHAGE
21-22
MODE D’EMPLOI 22
TÉLÉCOMMANDE FILAIRE 23
INSTALLATION ET MONTAGE 24-25
TECHNOLOGIE DMX 25-26
CARACTÉRISTIQUES TECHNIQUES 26
DECLARATIONS 27
PILOTAGE EN MODE DMX 55
ESPAÑOL
MEDIDAS DE SEGURIDAD 28-29
INTRODUCCIÓN 30
CONEXIONES, ELEMENTOS DE MANEJO Y ELEMENTOS DE VISUALI-
ZACIÓN 30-31
FUNCIONAMIENTO 31
MANDO A DISTANCIA POR CABLE 32
INSTALACIÓN Y MONTAJE 33-34
TECNOLOGÍA DMX 34-35
DATOS TÉCNICOS 35-36
DECLARACIÓN DEL FABRICANTE 36
CONTROL DMX 55
POLSKI
ŚRODKI OSTROŻNOŚCI 37-38
WPROWADZENIE 39
GNIAZDA, PANEL OBSŁUGI I WSKAŹNIKI 39-40
OBSŁUGA 40
PILOT PRZEWODOWY 41
USTAWIANIE I MONTAŻ 42-43
TECHNIKA DMX 43-44
DANE TECHNICZNE 44-45
DEKLARACJE PRODUCENTA 45
STEROWANIE DMX 55
ITALIANO
MISURE PRECAUZIONALI 46-47
INTRODUZIONE 48
RACCORDI, ELEMENTI DI COMANDO E DI VISUALIZZAZIONE 48-49
COMANDO 49
TELECOMANDO CON CAVO 50
INSTALLAZIONE E MONTAGGIO 51-52
TECNOLOGIA DMX 52-53
DATI TECNICI 53-54
DICHIARAZIONI DEL PRODUTTORE 54
CONTROLLO DMX 55
ENGLISH
YOU‘VE MADE THE RIGHT CHOICE!
We have designed this product to operate reliably over many years. Please read this User‘s Manual carefully, so that you can begin making
optimum use of your Cameo Light product quickly. Learn more about Cameo Light on our website WWW.CAMEOLIGHT.COM.
PREVENTIVE MEASURES
1. Please read these instructions carefully.
2. Keep all information and instructions in a safe place.
3. Follow the instructions.
4. Observe all safety warnings. Never remove safety warnings or other information from the equipment.
5. Use the equipment only in the intended manner and for the intended purpose.
6. Use only sufficiently stable and compatible stands and/or mounts (for fixed installations). Make certain that wall mounts are properly installed and
secured. Make certain that the equipment is installed securely and cannot fall down.
7. During installation, observ e the applicable safety regulations for your country.
8. Never install and operate the equipment near radiators, heat registers, ovens or other sources of heat. Make certain that the equipment is
always installed so that is cooled sufficiently and cannot overheat.
9. Never place sources of ignition, e.g., burning candles, on the equipment.
10. Ventilation slits must not be blocked.
11. This appliance is designed exclusively for indoor use, do not use this equipment in the immediate vicinity of water (does not apply
to special outdoor equipment - in this case, observe the special instructions noted below). Do not expose this equipment to flammable
materials, fluids or gases.
12. Make certain that dripping or splashed water cannot enter the equipment. Do not place containers filled with liquids, such as vases or
drinking vessels, on the equipment.
13. Make certain that objects cannot fall into the device.
14. Use this equipment only with the accessories recommended and intended by the manufacturer.
15. Do not open or modify this equipment.
16. After connecting the equipment, check all cables in order to prevent damage or accidents, e.g., due to tripping hazards.
17. During transport, make certain that the equipment cannot fall down and possibly cause property damage and personal injuries.
18. If your equipment is no longer functioning properly, if fluids or objects have gotten inside the equipment or if it has been damaged in
anot her way, switch it off immediately and unplug it from the mains outlet (if it is a powered device). This equipment may only be repaired
by authorized, qualified personnel.
19. Clean the equipment using a dry cloth.
20. Comply with all applicable disposal laws in your country. During disposal of packaging, please separate plastic and paper/cardboard.
21. Plastic bags must be kept out of reach of children.
FOR EQUIPMENT THAT CONNECTS TO THE POWER MAINS:
22. CAUTION: If the power cord of the device is equipped with an earthing contact, then it must be connected to an outlet with a protective
ground. Never deactivate the protective ground of a power cord.
23. If the equipment has been exposed to strong fluctuations in temperature (for example, after transport), do not switch it on immediately.
Moisture and condensation could damage the equipment. Do not switch on the equipment until it has reached room temperature.
24. Before connecting the equipment to the power outlet, first verify that the mains voltage and frequency match the values specified on the
equipment. If the equipment has a voltage selection switch, connect the equipment to the power outlet only if the equipment values and the
mains power values match. If the included power cord or power adapter does not fit in your wall outlet, contact your electrician.
25. Do not step on the power cord. Make certain that the power cable does not become kinked, especially at the mains outlet and/or power
adapter and the equipment connector.
26. When connecting the equipment, make certain that the power cord or power adapter is always freely accessible. Always disconnect the
equipment from the power supply if the equipment is not in use or if you want to clean the equipment. Always unplug the power cord and
power adapter from the power outlet at the plug or adapter and not by pulling on the cord. Never touch the power cord and power adapter
with wet hands.
27. Whenever possible, avoid switching the equipment on and off in quick succession because otherwise this can shorten the useful life of
the equipment.
28. IMPORTANT INFORMATION: Replace fuses only with fuses of the same type and rating. If a fuse blows repeatedly, please contact an
authorised service centre.
29. To disconnect the equipment from the power mains completely, unplug the power cord or power adapter from the power outlet.
30. If your device is equipped with a Volex power connector, the mating Volex equipment connector must be unlocked before it can be re-
moved. However, this also means that the equipment can slide and fall down if the power cable is pulled, which can lead to personal injuries
and/or other damage. For this reason, always be careful when laying cables.
31. Unplug the power cord and power adapter from the power outlet if there is a risk of a lightning strike or before extended periods of disuse.
32. The device must only be installed in a voltage-free condition (disconnect the mains plug from the mains).
33. Dust and other debris inside the unit may cause damage. The unit should be regularly serviced or cleaned (no guarantee) depending on
ambient conditions (dust etc., nicotine, fog) by qualified personnel to prevent overheating and malfunction.
34. Please keep a distance of at least 0.5 m to any combustible materials.
35. Power cables to power multiple devices must have a cross-section of at least 1.5 mm². Within the EU, the cables must correspond to
H05VV-F, or similar. Suitable cables are offered by Adam Hall. With these cables, you can connect multiple devices via the power OUT con-
nection to the power IN connection of an additional device. Make sure that the total current consumption of all connected devices does not
exceed the specified value on all connected devices (label on the device). Make sure to keep power cable connections as short as possible.
4
DEUTSCHFRANCAIS
ESPAÑOL
ITALIANOPOLSKIESPAÑOL
FRANCAIS
ENGLISH
ITALIANO POLSKI
DEUTSCHENGLISH
5
DMX
DMX
CAUTION:
To reduce the risk of electric shock, do not remove cover (or back). There are no user serviceable parts
inside. Maintenance and repairs should be exclusively carried out by qualified service personnel.
The warning triangle with lightning symbol indicates dangerous uninsulated voltage inside the unit, which may cause an
electrical shock.
The warning triangle with exclamation mark indicates important operating and maintenance instructions.
Warning! The fog outlet nozzle becomes very hot during operation. Do not touch the outlet nozzle during operation and
maintain a minimum distance of 50 cm from it! Ensure that the device has cooled down completely before cleaning or
transporting it!
Warning! This device is designed for use below 2000 metres in altitude.
Warning! This product is not intended for use in tropical climates.
CAUTION! HIGH VOLUMES IN AUDIO PRODUCTS!
This device is meant for professional use. Therefore, commercial use of this equipment is subject to the respectively applicable national accident
prevention rules and regulations. As a manufacturer, Adam Hall is obligated to notify you formally about the existence of potential health risks.
Hearing damage due to high volume and prolonged exposure: When in use, this product is capable of producing high sound-pressure levels (SPL)
that can lead to irreversible hearing damage in performers, employees, and audience members. For this reason, avoid prolonged exposure to
volumes in excess of 90 dB.
CAUTION! IMPORTANT INFORMATION REGARDING FOG MACHINES!
1. This product has been developed for professional use in the field of event technology and is not intended for use in the home!
2. Use only Cameo fog fluid (water-based) and never add flammable liquid to the container!
3. Switch off the fog machine and disconnect it from the power supply before filling the container!
4. Operate the fog machine only in well-ventilated rooms!
5. Do not leave the fog machine running unattended!
6. The fog outlet nozzle becomes very hot during operation. Do not touch the outlet nozzle during operation and maintain a minimum
distance of 50cm from it! Ensure that the device has cooled down completely before cleaning or transporting it!
7. The fog mist emitted is very hot! Never direct the outlet nozzle towards people or animals! RISK OF BURNING!
8. If the fog machine is installed overhead, ensure that people or animals are not allowed directly underneath it! RISK OF BURNING!
9. Never direct the fog outlet nozzle towards open flames or flammable materials!
INTRODUCTION
LED FOG MACHINE
CLSW1000
CLSW2000
CONTROL FUNCTIONS
4-channel DMX control
Cable remote control
FEATURES CLSW1000
LED fog machine with 9 x 3 W single LEDs (3 x R, 3 x G, 3 x B). Effect similar to pyrotechnics. DMX-512 control. Simultaneous operation
via cable remote control. Cable remote control included. Overheating protection and warning when canister is empty. Rubber feet. Traverse
assembly at any angle. Safety screw eyelets. Operating voltage 230 V AC/50 Hz, power consumption 800 W.
CONNECTIONS, OPERATING AND DISPLAY ELEMENTS
1
POWER IN
IEC mains socket with built-in fuse holder. A suitable power cable is included.
IMPORTANT:
Replace the fuse only with a fuse of the same type and of the same value according to the stamp on the device! In the event
of repeated fuse failure, please contact an authorised service centre.
2
POWER
On / Off switch for power supply to the device.
3
REMOTE
5-pin XLR socket for connection of the cable remote control (included).
4
DMX IN
Male 3-pin XLR socket for connection to a DMX control device (e.g. DMX console).
5
DMX OUT
Female 3-pin XLR socket for sending the DMX and remote control signal.
6
LED DISPLAY
The four-digit LED display shows the operating status, mode and other system information.
7
CONTROL BUTTONS
MODE: Selection of menu items. Move up one level in the menu structure.
ENTER: Confirm value changes.
UP and DOWN: Changing DMX address and settings.
2 6
7
1
3
5
4
FEATURES CLSW2000
LED fog machine with 12 x 10 W 4-in-1 RGBA LEDs. Effect similar to pyrotechnics. DMX-512 control. Simultaneous operation via cable
remote control. Cable remote control included. Overheating protection and warning when canister is empty. Rubber feet. Traverse assembly
at any angle. Safety screw eyelets. Operating voltage 230 V AC / 50 Hz, power consumption 1200W.
