Page 1/33
Wireless File Transmitter
WFT-E1A
E
INSTRUCTION MANUAL
COPY
2
Thank you for purchasing a Canon product.
Wireless File Transmitter WFT-E1A enables your EOS digital camera to send captured
images to an FTP server via a wireless or wired LAN.
It works with IEEE 802.11b and IEEE 802.11g wireless LANs and 100 Base-TX Ethernet
wired LANs.
EOS digital cameras compatible with the WFT-E1A are listed on Canonās Web site. Or
you can inquire at a Canon Service Center.
Image Transfer Overview
FTP server
FTP server
FTP server
Wireless LAN adapter
(Commercially available)
Wireless LAN access point
(Commercially available)
Ethernet port
Ethernet port
Wireless LAN-1
Images are directly transmitted (ad hoc) to
an FTP server equipped with a wireless
LAN adapter.
Wired LAN
The camera is connected via a LAN cable
to transmit images to the FTP server.
Wireless LAN-2
Images are transmitted (infrastructure) to
an FTP server via a wireless LAN access
point.
COPY
3
Introduction
Check that all the following items have been included with the WFT-E1A. If anything is
missing, contact your dealer.
* Battery Pack and Battery Charger are not included. If necessary, purchase them separately
(p.18).
* Be careful not to lose any of the items included with the WFT-E1A.
Ā”
Canon and EOS are trademarks of Canon Inc.
Ā”
Windows is a trademark or registered trademark of Microsoft Corporation in the United States and
other countries.
Ā”
Macintosh is a registered trademark of Apple Corporation in the United States and other countries.
Ā”
WPA is a registered trademark of Wi-Fi Alliance.
Ā”
All other corporate names and trademarks mentioned in this manual are the property of their
respective owners.
Item Check List
Ā¢
Wireless File Transmitter WFT-E1A
Ā¢
Normal Antenna NA-E1
Ā¢
Interface Cable IFC-15D4
Cable approx. 15 cm/0.5 ft long to connect to the <
a
> (IEEE 1394) port. Used when
the WFT-E1A is attached to the cameraās tripod socket.
Ā¢
Interface Cable IFC-150D4
Cable approx. 1.5 m/4.9 ft long to connect to the <
a
> (IEEE 1394) port. Used when
the WFT-E1A is placed some distance away from the camera.
Ā¢
Protective caps for cable
Two types are provided for the WFT-E1A and camera (EOS-1D series).
Ā¢
Tripod socket (with anti-rotation rubber pad)
Used when the WFT-E1A is attached to the cameraās tripod socket.
To prevent rotational slippage, a rubber pad is inserted between the WFT-E1A and camera.
Ā¢
Case
Case for the WFT-E1A. Can be mounted on a belt. Strap also provided.
Ā¢
WFT-E1/ WFT-E1A Utility Disk
Contains the instruction manual (what you are reading now) and software for creating the
settings ļ¬le.
Ā¢
Warranty card
COPY
