Page 1/28
User Manual
Power
Distribution
Unit
Table of Contents
Model List ...........................................................1
Introduction ........................................................1
Package Contents ....................................................... 1
For 1U Series ........................................................ 1
For 0U Series ........................................................ 2
For 2U Series ........................................................ 3
Safety Precautions ..................................................... 3
Proruct Features ........................................................ 4
1U 15A Series ....................................................... 4
Technical Specifications ....................................... 4
1U 20A Series ....................................................... 5
Technical Specifications ....................................... 5
0U 15A Series ....................................................... 6
Technical Specifications ....................................... 6
0U 20A Series ....................................................... 7
Technical Specifications ....................................... 7
0U 30A Series ....................................................... 8
Technical Specifications ....................................... 8
2U Series .............................................................. 9
Technical Specifications ....................................... 9
Installation Guide ................................................10
Horizontal Installation ............................................... 10
For 1U Model ....................................................... 10
For 2U Model ....................................................... 11
Vertical Installation .................................................. 13
For 1U Model ....................................................... 13
For 0U Model with Bracket .................................. 13
For 0U Model with Keyhole Mount ..................... 15
Electrical Installation ................................................. 15
Network Installation .................................................. 16
Operation ............................................................17
Metered Readout ..................................................... 17
Basic Operation .................................................... 17
PDU Status Screen................................................ 17
Current Level ................................................ 17
Input Voltage ................................................ 17
Power ........................................................... 17
IP Address .................................................... 17
Outlet Control (switched series only) .......... 17
LED Reversal (0U series only) ....................... 17
Environmental Monitoring (optional) ...................... 18
LED Indicators ........................................................... 18
Device Reset ............................................................. 18
Remote Management .............................................. 18
Unattended/Automatic Shutdown ........................... 19
Firmware Upgrade...............................................19
Troubleshooting ..................................................20
Frequently Ask Questions (FAQ) ..........................20
Conformance Approvals ......................................20
Customer Service & Warranty .............................21
Product Registration ................................................. 21
CyberPower International ........................................ 21
Limited Warranty ..................................................... 21
Appendix A-Hyper Terminal ................................22
Appendix B-Power Device Network Utility...........23
Overview .................................................................. 23
Installation ................................................................ 23
Launch Program ....................................................... 24
Getting Started ......................................................... 24
Advanced Settings .................................................... 25
1
For more information on CyberPower products, visit www.CPSww.com
1U Switched Series
PDU15SW8FNET
PDU15SWHVIEC8FNET
PDU20SW8FNET
PDU20SWT8FNET
PDU20SWHVIEC8FNET
1U Monitored Series
PDU15M8FNET
PDU15MHVIEC8FNET
PDU20M8FNET
PDU20MT8FNET
PDU20MHVIEC8FNET
0U Switched Series
PDU15SWV16FNET
PDU20SWVT24FNET
PDU20SWVHVT24FNET
PDU30SWVT24FNET
PDU30SWVHVT24FNET
0U Monitored Series
PDU15MV16FNET
PDU20MVT24FNET
PDU20MVHVT24FNET
PDU30MVT24FNET
PDU30MVHVT24FNET
2U Switched Series
PDU30SWT16FNET
PDU30SWHVT16FNET
2U Monitored Series
PDU30MT16FNET
PDU30MHVT16FNET
Package Contents
(For 1U Series)
Model List
Introduction
PDU
6 (M3x6) Cord Retention
Tray Mounting Screws
(Includes two spares)
6 (M5x12) Screws / 6 Washers
(Includes two spares for each)
RJ45/DB9 Serial Port
Connection Cable
Power Cord 10 feet,
IEC-320 C19/ IEC-320 C20
(PDU20SWHVIEC8FNET/
PDU20MHVIEC8FNET Model Only)
Mounting Bracket: 2 short & 2 long
10 (Flat Head M4x8) Bracket Mounting
Screws (Includes two spares)
Power Cord 10 feet,
IEC-320 C13/IEC-320 C14
(PDU15SWHVIEC8FNET/
PDU15MHVIEC8FNET Model Only)
Cord Retention Tray
Cable Ties / Qty. 10 User Manual / Registration Card / CD
Documentation
Registration
Card
C
yber
Pow
er
R
e
l
i
a
b
i
l
i
t
y.
Q
u
a
l
i
t
y.
Va
l
u
e
.
R
U
s
e
r
's
M
a
n
u
a
l
