Page 1/5
page 1 of 7
Operating manual
3214 JH4
Product type, manufacturing date (calendar week/year of construction)
and if required, conformity mark can be found on the nameplate on the
product.
Please provide us with the contents of the nameplate when making
enquiries about the product.
ebm-papst St.Georgen GmbH & Co. KG
Hermann-Papst-Straße 1
D - 78112 St.Georgen
Phone: +49 (0) 7724 / 81-0
Fax: +49 (0) 7724 / 81-1309
info2@de.ebmpapst.com
www.ebmpapst.com
As per: 06.03.2024
Version: 1 10
Article number: 9693520181
Original operating manual
INDEX
1 SAFETY REGULATIONS AND INFORMATION 1
2 INTENDED USE 4
3 TECHNICAL DATA 4
4 CONNECTION AND COMMISSIONING 5
5 FAULTS, POSSIBLE CAUSES AND REMEDIES 6
6 COMPLIANCE 6
1 SAFETY REGULATIONS AND INFORMATION
Read the operating manual carefully before commencing work at the
product. Pay attention to the following warnings to avoid risk to
persons or malfunctioning.
This operating manual is an integral part of the product.
In the event of resale or change of ownership the operating manual
must accompany the product. This operating manual may be copied
and provided as information on potential risks and their avoidance.
Hazard classification of warning notices
The following risk ratings are used in this operating manual to denote
potential risk situations and important safety instructions:
DANGER
This is a potentially dangerous situation
and warns of an impending health risk
or risk of fatal injury if this warning is
not observed. Observe this warning.
WARNING
The dangerous situation can occur and
can result in major or fatal injuries if the
warning is not observed. Work with
extreme care.
CAUTION
The dangerous situation can occur and
can result in minor injuries or damage
to property if the warning is not
observed.
NOTE
A potentially dangerous situation can
occur and results in damage to
property if not avoided.
Qualification of personnel
Only skilled electricians are permitted to install the product, to carry out
the test run and to work at the electrical unit.
Only instructed and authorized skilled personnel are permitted to
transport, unpack, operate and service the product.
Basic safety regulations
Safety risks related to the product must be reassessed after installing
in the final device.
The operating manual was developed in accordance with European
market requirements and may need adapting to the market
requirements of the country in question.
When working at the product, observe the following:
 Do not make any changes to the product.
WARNING
Impermissible high load
 Stop the product immediately after
impermissible loading (e.g. impact,
heat, overvoltage).
page 2 of 7
Electrical voltage and current
DANGER
Electrical voltage
Regularly check the electrical
equipment of the product.
 Eliminate immediately loose
connections and defective cables.
Safety and protective functions
DANGER
Missing safety device and faulty
protective equipment.
Without protective equipment severe
injuries can occur, e.g. by taking hold of
the rotating equipment.
 Operate the product with protection
guards only.
Electromagnetic radiation
Electromagnetic compatibility (EMC) may affect the system integration
of the product due to interaction.
 Ensure the electromagnetic compatibility of the entire system.
Moving parts
DANGER
Self-starting product
If voltage is applied, the motor
automatically restarts after a mains
failure or when blocking has been
eliminated.
 Do not stand in the danger zone of
the product.
 Switch off the mains voltage when
working on the product and secure
against switching on again.
DANGER
Rotating impeller
Contact with the impeller may result in
injuries. Long hair, loose-fitting
garments and jewellery can be caught
and pulled into the product. Risk of
injury.
 Before starting the product, ensure
that it is securely fixed and that the
guards are in place.
 Do not wear loose-fitting garments
or jewellery when working on
moving parts.
 Protect long hair by wearing a hair
net.
DANGER
Blocking of escape routes
The product can create dangerously
high pressure.
 When operating the product ensure
that there is adequate supply and
exhaust air.
WARNING
Parts transported by the airflow
The product can transport small parts
in the airflow and catapult them out.
 Ensure that there are no loose
small-parts in the intake and
exhaust area.
 Do not stand in the danger zone of
the product.
CAUTION
High risk of fire spreading
Can cause fire to spread.
 Never direct the airflow
(intake/exhaust side) at a potential
source of fire.
Hot surface
CAUTION
High temperature at motor housing.
Risk of burns
 Provide adequate protection against
accidental contact.
Emission
DANGER
Acoustic alarms can be overheard.
Alarm signals can be overheard
 Take technical protective measures,
e.g. optical warnings.
WARNING
A noise pressure level higher than
70dB(A) is possible depending on
the installation and operating
conditions.
Risk of deafness due to noise.
 Take technical protective measures.
Provide operating personnel with
protective equipment, e.g. ear
protection.
Transport
Only transport the product in its original packaging. Secure during
transport.
The vibration values, temperature and climate ranges should not
be exceeded during transport.
Storage
 Store the device, partially or fully assembled, in a dry place,
protected against the weather and free from vibration, in the
original packaging in a clean environment.
 Protect the device against environmental effects and dirt until final
installation.
 To guarantee trouble-free operation and the longest possible
service life do not store the device for more than one year.
 Even devices explicitly intended for outdoor use are to be stored as
described prior to commissioning.
 Maintain the storage temperature, see Chapter 3, Technical Data
page 3 of 7
Cleaning
NOTE
Product damaged during cleaning
 Clean the product carefully with a
moist cloth without applying
pressure to the rotor. Do not use
cleaning agents that contain acids,
caustic solutions or solvents.
Disposal
When disposing of the product, observe all requirements and
regulations that are relevant in your country.
Product Specifications
| Brand: | Ebm-papst |
| Category: | Ventilator |
| Model: | 3214 JH4 |
