A5107 / Rev.4

www.entes.com.tr

DTR-25 User Manual and

Menu Map

Dudullu OSB; 1. Cadde; No: 23 34776 Umraniye - ISTANBUL / TURKIYE

Tel : 0 216 313 01 10 Fax : 0 216 314 16 15

ESC SET

Day

dd.mm.yy

Hour

Relay on/off status

ESC Button

SET Button

UP Button

DOWN Button

Date

HH:mm:ss

Relay AUTO/MANUAL

status

Battery Status

Used Summer/Winter

Time status

Selected days for the

shown program while in

Program Menu

1 2 3 4 5 6 7

C1: C2:

AUTO

MANUAL

DTR-25, which has a real time clock, is an electronic timer that calculates the Fajr, Dhuhr, Asr, Maghrib

and Isha’a Salah times additional to the sunset and sunrise periods automatically. It is designed for

controlling the devices which are connected to its contacts according to Salah times, sunset, sunrise and

the time periods which are programmed by the user.

ESC Button :

SET Button :

DOWN Buttons:

It is used to switch between monitoring menus. In the programming mode, it is used to

cancel a parameter change or to return to the previous menu.

It is used to switch between monitoring menus. When it is pressed for 3 seconds,

programming mode is entered. In the programming mode, it is used to apply a parameter

change or to enter to a menu.

In the monitoring menu, it is used to switch between programs to show their activity in a

day. When the DOWN button is pressed for 3 seconds, C1 relay goes into manual mode

and when the UP button is pressed for 3 seconds, C2 relay goes into manual mode. In

the programming menu; it is used to browse between menus, to select parameters and

to adjust values with digits.

Precautions for Installation and Safe Use

If below precautions are not properly observed and carried out, it may result in cases with injury or death.

- Disconnect power before working on the device.

-When device is connected to the network, do not remove the front panel.

-Do not clean the device with solvent or similar items. Only clean with dry cloth.

-Verify correct terminal connections before energizing the device.

-Install the device on the electrical panel.

-Contact your authorized reseller in case problems occur with your device.

No responsibility is assured by the manufacturer or any of its subsidiaries for any consequences

rising out of the use of this material.

- The output loads connected to the relays do not function if auxiliary supply is absent. Even if the

relay status is monitored as “on”( and/or ), auxiliary supply is a must for the operation.

Salah Times are based on the calendars which are prepared by the Turkish Presidency of Religious

Affairs and the calculation settings are controlled in referrance with the Calendars of the Turkish

Presidency of Religious Affairs.

The device shouldn’t be used for anything other than controlling relays before or after the Salah Times.

The Salah Times may differ +/- 2 minutes from the times which are listed in the calendar. For a more precise

time calculation, the coordinates of the device should be entered manually from the REGIONAL SETTING

menu.

- There are two reserves in the device. Programmed data is protected by these reserves against power

outages.

- Battery shelf life is 5 years.

- Reserve battery should only be changed by the authorized service.

MANUAL MODE :

In order to use the relay outputs manually, DTR-25 has to be in the monitoring mode. The DOWN button

is used to switch the C1 relay to manual mode and the UP button is used to switch the C2 relay to manual

mode. When the UP or DOWN button is pressed for 3 seconds, “MANUAL” indication appears on the

screen. If this is done while the relay C1 or C2 is activated, that relay will be deactivated. If it is done while

the relay C1 or C2 is deactivated, no switching will occur. After the relay C1 or C2 is in the manual mode;

when the DOWN button is pressed again for 3 seconds, C1 relay will exit the manual mode and when the

UP button is pressed again for 3 seconds, C2 relay will exit the manual mode. The relay will stay activated

or deactivated according to the program flow. When both of the the relays are in manual mode, “AUTO”

indication will dissappear from the screen.

3 4

MONITORING MENU :

SET and ESC buttons are used to switch between menus in the monitoring mode. If the device is left

unattended for 60 seconds in any menu other than the real time and date, it returns to the real time and

date screen.

Program activity time menu shows the programs, which are stored on the device, in order according to

program activity time. The active or finished programs can be shown with UP or DOWN buttons. The

programs with a sign next to them are the programs which are still active.

Salah Time for

Isha’a

Sunrise Time

Sunset Time

Program

Activity Time

Activation

Time for C1

Relay(Hours)

Operation

Count for C1

Relay

Activation

Time for C2

Relay(Hours)

Operation

Count for C2

Relay

Salah Time for

Fajr

Real Time

and Date

16:12:10
