1
1
MPR-4X
MPR-4X-OG/OGT
MPR-4X-PM
Series
Network Analyzer
User Manual
www.entes.eu
2
1. SAFETY AND WARNINGS....................................................................................................... 3
Warning ................................................................................................................................3
Safety.....................................................................................................................................3
Warranty ................................................................................................................................3
2. OPERATING CONDITIONS ..................................................................................................... 4
3.INTRODUCTION ....................................................................................................................... 5
3.1 General Features .............................................................................................................5
3.2 Applications......................................................................................................................6
3.3 MPR-4X Series Product...................................................................................................6
3.4 Overview and Interface .................................................................................................... 7
3.4.1 Terminals ...................................................................................................................7
3.4.1.1. MPR-4X Series Rear Panel ...................................................................................7
3.4.1.2. MPR-4X-OG/OGT Series Rear Panel ..................................................................8
3.4.1.3. MPR-4X-PM Series Rear Panel ...........................................................................8
3.4.2. Screen .....................................................................................................................9
3.4.3. Button Functions .......................................................................................................10
3.5 Terminal Structure ............................................................................................................11
4. CONNECTION ......................................................................................................................... 12
4.1. 3P4W (Three Phase Four Wires) Connection ................................................................12
4.2. 3P3W (3 Phase 3 Wires) Connection .............................................................................12
4.3. Aron without Neutral Connection ....................................................................................13
4.4. 3P4W BLN (3 Phase Balanced with Neutral) Connection ..............................................13
4.5.
3P3W BLN (3 Phase Balanced without Neutral) Connection ................................................13
4.6. Connection Test ..............................................................................................................14
5. OPERATING INSTRUCTIONS ................................................................................................. 15
5.1 Measurement Screens.....................................................................................................15
5.1.1 Current, Voltage and Frequency Screens..................................................................15
5.1.2 Power and Power Factor Screens ...........................................................................17
5.1.3 Energy and Time Screen ...........................................................................................18
5.1.4.
THD and Harmonics Screens
(MPR-46X, MPR-47X ve MPR-42-OGT) ......................................... 21
5.1.5. Minimum, Maximum and Demand Screens ............................................................. 22
5.1.6. Ethernet Parameter Displaying Screens (MPR-4XSE) ............................................. 27
5.2 Setup Screen ...................................................................................................................30
5.2.1 Device Installation Settings........................................................................................30
5.2.2. Display Settings ........................................................................................................35
5.2.3. Time Settings ............................................................................................................36
5.2.4. RS-485 Communication Settings..............................................................................38
5.2.5 Ethernet Communcation Systems .............................................................................40
5.2.6 Input Parameter Settings ...........................................................................................43
5.2.7 Output Parameter Settings ........................................................................................45
5.2.8. Recording Settings ...................................................................................................46
5.2.9. Selecting Parameter to Be Recorded .......................................................................46
5.2.10. Pulse Input Settings ............................................................................................... 49
5.2.11. Pulse Output Settings ............................................................................................51
5.2.12. Operating Hours Settings .......................................................................................53
5.2.13. Alarm Settings.........................................................................................................54
5.2.14. Tari󰀨 Settings ..........................................................................................................57
5.2.15. Reset Settings ...........................................................................................................58
5.2.16. System Settings ......................................................................................................61
5.2.17. Analog Output Settings ...........................................................................................64
5.3.Reporting Screen ............................................................................................................68
6. TECHNICAL FEATURES AND APPENDIX .............................................................................. 69
INDEX
3
1. SAFETY AND WARNINGS
Warning
Installation of this device on the panel should be carried out only by authorized
personnel. The manufacturer cannot be held responsible in any way for any errors that
may occur if the instructions set out in this document are not followed. Please read the
safety information and warnings carefully before installation.
• Disconnect the power on the line that will come to the device on the panel
beforeconnecting the device. If it is not done, there is a risk of fatal injury and a risk
of device failure.
• Before conecting, check the back panel of the device to make sure that the correct
terminals are properly connected.
• Device should not be connected to network if it has any damage.
• Please do not open front panel or inside of the device if it is still connected to
network.
• Do not attempt to clean the device with a solvent or another similar material. Use
only a dry piece of cloth.
• Secondary side of current transformators shall not be kept open while primary side
of them is still energized. It may cause damage on device, re and some serious
injury.
• Please x the connection of current transformers with using washer or cable lug in
order to protect against mechanical pulling.
• Please always use appropriate supply voltage for the device.
• Contact your authorized seller in case of any problems with your device.
• Device is only for panel mounting.
• F Type fuse must be used and its current limit must be 1 A.
Safety
Read the entire user manual before using the device.
• A switch or circuit breaker must be connected between the network and the
auxiliary supply of the device.
• Connected switch or circuit breaker must be in close proximity to the device.
• Connected switch or circuit breaker must be marked as the disconnecting device for
the equipment
Warranty
Device has a 2 (two) year warranty. Any repairs on the device must be done only by
the manufacturer. Otherwise, the device warranty will be invalid.
