Page 1/12

Vanco Part Number

EV4K2006

4K HDMI® Extender

over Single Category

5e/6 Cable with POE

www.vanco1.com • 800.626.6445

over single Cat5e/Cat6 Cable

4K HDMI®

EXTENDER

www.vanco1.com

800.626.6445

1. Do not expose this unit to water, moisture, or

excessive humidity.

2. Do not install or place this unit in a built-in

cabinet, or other conned space without

adequate ventilation.

3. To prevent risk of electrical shock or re

hazard, due to overheating do not obstruct

unit’s ventilation openings.

4. Do not install near any source of heat,

including other units that may produce heat.

5. Do not place unit near ames.

6. Only clean unit with a dry cloth.

7. Unplug unit during lightening storms or when

not used for an extended period of time. A

surge protector is strongly recommended.

8. Protect the power cord from being walked on

or pinched, particularly at the plugs.

9. Use unit only with accessories specied by

the manufacturer.

10. Refer all servicing to qualied personnel.

CAUTION

HDMI is a very complex technology requiring continuous authentication of the signal and the same

video resolution and audio settings on all electronic equipment in the system. When there are multiple

sources and displays, the video resolution and audio setting on all connected units must be adjusted

to correspond with that of the display having the lowest video and audio capability.

WARNING

DEAR CUSTOMER

Thank you for purchasing this product.

For optimum performance and safety, please

read these instructions carefully before connecting, operating or

adjusting this product. Please keep this manual for future reference.

This product is 100% inspected and tested in the United States to verify

HDMI performance parameters.

www.vanco1.com

800.626.6445

INTRODUCTION

FEATURES

4K HDMI® over Single Cat5e/Cat6 Cable Extender

Part # EV4K2006

• Allows HDMI audio/video signals to be transmitted using a single Cat5e or Cat6 Cable

• Transmission Range: Extends 4K@60Hz, 4:4:4 Chroma up to 164ft/50m and 4K@30Hz, 4:4:4 Chroma

and HDR up to 130ft/40m over a single Cat5e/6 cable

• Features Power over Ethernet (PoE) Technology which transmits power over Cat5e/Cat6, allowing the

transmitter and receiver to be powered off of a single power supply

• Wideband Bi-directional IR system allowing for control of source or display (IR accessories included)

• Wideband IR signal from 20KHz to 60KHz

• Features Auto EDID and EQ Management for plug and play installation

• HDR10 Compatible

• Works with HDMI and HDCP compliant devices

• HDCP 2.2 compliant

• Slim and compact design

• Pure uncompressed 7.1ch digital audio

• Supports DTS-HD and Dolby TrueHD high bit rate audio

• Dimensions: 2.7” (68.58mm) W x .7” (17.78mm) H x 3.25” (82.55mm) D

The Evolution by Vanco EV4K2006 HDMI Extender over Single Cat5e/6 with Bi-directional IR, auto EDID/EQ, and Bi-directional

PoE extends 4K ultra high denition video with HDR and audio signals, IR, and power. Extends 4K@60Hz, 4:4:4 Chroma

Subsampling and HDR up to 164ft/50m, and 4K@30Hz, 4:4:4 Chroma Subsampling, and HDR up to 130ft/40m. Bi-

directional Power over Ethernet (PoE) Technology transmits power over Cat5e/6, allowing either the Transmitter or Receiver

to be powered without the use of a power supply. No EDID or EQ adjustments are necessary as the units automatically

adjusts for compatibility and gain. This extender set also features a newly redesigned slim and compact chassis for easy and

exible installations. This product fully supports DTS-HD and Dolby TrueHD audio formats and is HDCP compliant. In addition,

bi-directional IR pass-through allows for source or display control. For extending HDMI over a single Cat5e/6 with IR at a long

distance, with Power over Ethernet, the EV4K2006 is a great plug and play solution!

The EV4K2006 includes two units: transmitting unit (EV4K2006-TX) and receiving unit (EV4K2006-RX). The transmitting unit

is used to capture the HDMI input with IR signals and carries the signals via one cost effective Cat5e/6 cable. The receiving

unit is responsible for equalizing the transmitted HDMI signal and reconstructing IR signals. The EV4K2006 offers the most

convenient solution for HDMI extension over a single Cat5e/6 with Power over Ethernet and is the perfect solution for any

application.
