Approved for public release: Teledyne FLIR approved [FLIRGTC-SBA-010].

WWARN

ARN

ARNARNING:

ING:

ING:ING: Information contained herein is classified as EAR99 under the U.S. Export Administration Regulations. Export, reexport or div sion contrary to U.S. law is prohibited.er

HADRON ™640R

INTEGRATION GUIDE

August 2023 | ver. 1.12

Approved for public release: Teledyne FLIR approved [FLIRGTC-SBA-010].

WWARN

ARN

ARNARNING:

ING:

ING:ING: Information contained herein is classified as EAR99 under the U.S. Export Administration Regulations. Export, reexport or div sion contrary to U.S. law is prohibited.er

CAMERA SPECIFICATIONS

Thermal Camera Visible Camera

Core Boson®OMNIVISION™

Resolution 640 x 512 (VGA) 64MP

HFOV 32⁰ ⁰67

Input MIPI, I2C, USB 3.0 MIPI, I2C

Output MIPI (2-lane), USB 3.0 MIPI (4-lane)

Other Radiometric Configurable to Low Light
