INSTRUCTION MANUAL/MANUAL DE USUARIO/
MODE D’EMPLOI/MANUAL DE INSTRUÇÕES
AS-6060
HI-FI STEREO AMPLIFIER BLUETOOTH
®
/USB/FM
AMPLIFICADOR ESTÉREO HI-FI BLUETOOTH
®
/USB/FM
AMPLIFICATEUR STÉRÉO HI-FI BLUETOOTH
®
/USB/FM
AMPLIFICADOR ESTÉREO HI-FI BLUETOOTH
®
/USB/FM
EN
- 2 -
DESCRIPTION
- New amplifier with unique FONESTAR design, high reliability and precision during playback.
- An exceptional finish with a brushed aluminium front and high contrast high visibility LCD display.
- Stylish and practical design, can be integrated into any furniture, whether for home or professional use.
- A wide range of playback options (Bluetooth
®
, USB y FM) and audio inputs make it highly versatile and
adaptable.
- Two microphone inputs to use as Karaoke and sing over your favorite songs.
CONTROLS AND FUNCTIONS
FRONT PANEL
AS-6060
STEREO AMPLIFIER
CAUTION : SHOCK HAZARD - DO NOT OPEN
RISK OF FIRE-REPLACE FUSE AS MARKED
CA UT IO N
RISK OF ELECTRIC SHOCK
DO NOT OPEN
DVD
LINE
ECHO MIC TONE MIC VOL BASS TREBLE BALANCE
AUX
VOL
CD
DIGITAL /
1 2 3 4
10 11 12 13 14 15 16 17
18
5 6
1 2 43 5 6 7
7
1
2
3
4
5
6
7
8 9
8
9
a b c
1.- POWER: on/off switch for the amplifier.
2.- {: A long press decreases the volume of the player. A short press in Bluetooth or USB mode skips to
the previous audio track; in FM mode it skips to the previous stored frequency.
3.- 12: in Bluetooth or USB mode it plays/stops audio playback; in FM mode, it auto-stores all detected
frequencies with sufficient signal quality.
4.- }: a long press increases player volume. A short press, in Bluetooth or USB mode skips to the next
audio track, in FM mode skips to the next stored frequency.
5.-
: in USB mode, allows you to select the repeat mode: ONE OR ALL.
6.- Player information display.
7.-
: in USB mode, activates random play (RAND).
8.- MODE: short presses of this button allow you to change the mode on the player to choose the
desired audio source: Bluetooth, aux, FM radio, or USB device, provided the input selector is in the
MP3/AUX/FM/
position.
9.- USB port for audio file playback.
10.- Input selection control for playback: rear panel line inputs (LINE and DVD), digital or line inputs
(DIGITAL - CD) or the player (MP3/AUX/FM//
).
11.- ECHO: control that adds an echo or reverb effect to the MIC 1 and MIC 2 microphone signal.
12.- MIC TONE: adjusts the equalization of MIC 1 and MIC 2 signals, allowing you to enhance or attenuate
frequencies to improve sound.
13.- MIC VOL: control that regulates the volume of MIC 1 and MIC 2 microphone inputs.
14.- BASS: boosts/attenuates low frequencies.
15.- TREBLE: boosts or attenuates high frequencies.
16.- BALANCE: allows to adjust the sound to achieve a balanced result by giving more emphasis to the L
or R channel on the output signal.
17.- AUX: stereo auxiliary input for connecting audio devices such as phones, computers, etc. 3.5 mm
stereo jack connector.
18.- VOL: headphone output volume control.
EN
- 3 -
REAR PANEL
AS-6060
STEREO AMPLIFIER
CAUTION : SHOCK HAZARD - DO NOT OPEN
RISK OF FIRE-REPLACE FUSE AS MARKED
CA UT IO N
RISK OF ELECTRIC SHOCK
DO NOT OPEN
DVD
LINE
ECHO MIC TONE MIC VOL BASS TREBLE BALANCE
AUX
VOL
CD
DIGITAL /
1 2 3 4
10 11 12 13 14 15 16 17
18
5 6
1 2 43 5 6 7
7
1
2
3
4
5
6
7
8 9
8
9
a b c
1.- FM: antenna input for FM digital tuner.
2.- DVD, LINE, CD: stereo line inputs for connecting audio devices such as mixers, computers, players,
etc. 2 x RCA connectors. To play one of these inputs it will be necessary to set the input selector to the
corresponding DVD, LINE or CD position.
3.- CD - DIGITAL INPUT: analogue and digital input with selector. To play one of these inputs it will be
necessary to set the input selector switch to the corresponding DIGITAL/CD position and the selector
switch of these inputs to CD.
AS-6060
STEREO AMPLIFIER
CAUTION : SHOCK HAZARD - DO NOT OPEN
RISK OF FIRE-REPLACE FUSE AS MARKED
CA UTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
DVD
LINE
ECHO MIC TONE MIC VOL BASS TREBLE BALANCE
AUX
VOL
CD
DIGITAL /
1 2 3 4
10 11 12 13 14 15 16 17
18
5 6
1 2 43 5 6 7
7
1
2
3
4
5
6
7
8 9
8
9
a b c
a.- Stereo line input for connection of audio devices such as mixing
consoles, computers, players, etc. 2 x RCA connectors.
b.- CD input selector - DIGITAL INPUT. In the CD position it enables
the 2 x RCA digital input and in the DIGITAL position it enables the
optical (Toslink) and coaxial (RCA) digital inputs.
c.- Digital inputs for the connection of audio devices such as TVs,
computers, players, etc. Toslink and RCA connectors. The optical input has priority over the coaxial
input when switching on the equipment, provided that both inputs have a signal; otherwise, the
input that has a signal will be played.
4.- MIC 1, MIC 2: balanced 6.3 mm jack plug microphone inputs.
5.- SPEAKER OUTPUT: stereo output of 60 + 60 W RMS for connection of 4-16 Ω low impedance speakers.
Screw terminals or bananas.
6.- AC power socket.
7.- FUSE: fuse holder.
PLAYER REMOTE CONTROL
1.-
: on/StandBy button on the player
2.- CH-/CH+: in radio mode, a short press allows to skip to the previous/next stored
station.
3.-
/ : In Bluetooth, USB and SD mode, allows you to skip to the previous/next
audio track; in radio mode, a short press allows you to fine-tune by decreasing/
increasing the frequency by 0.1 MHz.
4.- VOL-/VOL+: increase/decrease the volume of the player.
5.- 0-9: numeric buttons. In USB mode, direct select to play a specific audio track. In
radio mode, allows to select the stations stored in the memory.
6.-
: in USB mode, allows to select the repeat mode. RAND (RANDOM), ONE (ONE),
OR ALL (ALL).
7.- MODE: allows you to change the operating mode between: Bluetooth, USB, AUX and FM radio.
8.- EQ: in Bluetooth or USB mode, allows to switch between the different existing EQ (EQ 0-5).
1.-
: in Bluetooth or USB mode plays/stops audio playback; in FM mode, it auto-stores all detected
frequencies with sufficient signal quality; in AUX mode, mutes audio output.
AS-6060
STEREO AMPLIFIER
CAUTION : SHOCK HAZARD - DO NOT OPEN
RISK OF FIRE-REPLACE FUSE AS MARKED
CAU TIO N
RISK OF ELECTRIC SHOCK
DO NOT OPEN
DVD
LINE
ECHO MIC TONE MIC VOL BASS TREBLE BALANCE
AUX
VOL
CD
DIGITAL /
1 2 3 4
10 11 12 13 14 15 16 17
18
5 6
1 2 43 5 6 7
7
1
2
3
4
5
6
7
8 9
8
9
a b c
