Page 1/18
Free Game
Platform Download
GameSir Gamepad
User Manual
Model No.: GameSir-G3v
www.GameSir.hk
※Product Introduction
GameSir Game controller luxury Edition (G3v) is connected by Bluetooth, 2.4GHz and wired, it applies to Android devices (above 4.0
version), Windows PC, and PlayStation3 consoles. This Game controller can identify all the devices automatically, no need driver
installation, button mapping setting, or root.
Android / Windows / PS3
3.7V 5.2V～
Android Standard /
Mouse Simulation / PS3
64*172*208mm
160*104*59mm
1A 2A～
GameSir-G3v
-20 65℃ ～ ℃
20 80%～
Model No.
Working Temp.
Working Humidity
Connection Types
Charging Time
Working Distance
Battery Capacity
Net Weight
Bluetooth / 2.4GHz / Wired
Approx. 7m
600mA
189g
2 3H～
GameSir Gamepad
Product Name
Working Platforms
Working Modes
Charging Voltage
Charging Current
Gift Box Size
Product Size
English
※Product Specification
1
※Product Function
Power On / Off
Power LED Indicator
Charging Indication
1. Charge through charging cable
2. Charge under sleeping mode
1. Power On: Press HOME button for 2 seconds to start.
2. Power Off: Press HOME button for 5 seconds to power off.
LED 1-LED 4 lights: more than 75% battery power left
LED 1-LED 3 lights: 50%-75% battery power left
LED 1-LED 2 lights: 25%-50% battery power left
Only LED 1 light: 10%-25% battery power left
LED 1 shining: less than 10% battery power left.
When connect the charging cable, the LED lights from Number 1 to Number 4 will lights in turns, the four lights keep on when it is fully
charged.
When connect the charging cable, the Game controller wakes up and enters current mode, no signal receiving after 1 minute. LED lights
from number 1 to 4 will lights in turns. Four LED lights keep on when it is fully charged.
LED-1 LED-2 LED-3 LED-4
※Product Overview
Left Stick
Indicate Lights:
Right Stick
TURBO
L3
( press Left stick )
SELECT
D-Pad
START
HOME
CLEAR
R3
( press Right stick )
X
Y
A
B
L2
L1 R1
R2
Charging Port
32
