ED504
Pure-Series
Installation Guide
Status
Green – power on
Yellow (blinking) - booting
Red – boot failed
Uplink
Green – link ok
O – no link
Internet (IP connectiviy)
Green – connected (DNS available)
Green (blinking) – connection failed (no DNS available)
O – no IP connectiviy
Phone
Green – voice sevice registered and ok
Green (blinking) – voice sevice failed to register
O – no voice sevice present or registered
Wireless (WiFi)
Green – wireless nework . GHz andor  GHz active
O – wireless neworks inactive
Mode buton
Activate WPS – press and hold  seconds
DisableEnable WiFi – press and hold  seconds
LED & buton oveview Pot oveview
Pure ED can be connected to an Ethernet based broadband nework
through WAN intefaces DSL (grey) and Ethernet WAN (red).
Geting stated
Check if the following items are in
the gitbox:
• Genexis Pure ED
• Power adapter
• RJ Nework cable (red, large connector)
• RJ DSL cable (grey, small connector)
• Labels (self-adhesive, x)
• Rubber feet (self-adhesive, x)
• Plugs & screws (x)
Label position
The product label is positioned on the botom
of the active device.
Placement
Pure suppots wo placement options;
standing and mounted to a wall. It is
recommended to place the device ‘away’
from obstacles and objects.
Standing
. Place the device on a lat suface.
Wall mount
. Download and print the drilling guide from
htps:genexis.eudownload-potalpure
. Use the drilling guide to drill the holes,
inset plugs and put screws into place.
. Remove the stand from the device by
sliding it towards the front.
. Store the stand in a safe place.
. Use the wall mount points on the back of
the Pure ED to mount the device to
the screws.
Warning: do not cover the device with
anything, this will intefere with the
ventilation of the Pure.
Operation Temperature °C ~ °C
Multiple languages of this document and additional product information are availableon
htps:genexis.euproductpuredownloads
Installation guide
