Page 1/20
• Helmet should sit level on your head and low on your forehead
• Adjust the strap sliders below the ear on both sides.
• Buckle the chin strap. Adjust strap until it is snug.
• No more than two fi ngers should fi t between the strap and your chin.
• A proper fi tting helmet should be comfortable and not rock forward/back-
ward or side to side.
• Always read the user manual that comes with your helmet to make sure it
is fi tted and attached properly to the wearer’s head according to the fi tting
instructions described in the user manual.
Check
www.Huffybikes.com/contact
for the current contact information
WARNING:
ALWAYS WEAR YOUR HELMET
WHEN RIDING THIS PRODUCT!
Owner’s Manual
for
Motorcycle Ride On
Please read and fully understand this manual
before operation.
Save this manual for future reference.
This manual contains important safety, assembly, operation
and maintenance information.
H-3w-MC-Rideon EN 041916 m0356
Copyright Huffy Corporation 2016
BC
Date Code Label
Here
2
Owner’s Manual Index
Safety and Warnings
• User and Battery Warnings ...................................................................3-4
• Radio Frequency ...................................................................................4
• Charging Drive Motor Warnings ............................................................5
Assembly
• Parts List ...............................................................................................6-7
• Vehicle Assembly .................................................................................8-11
Operation
• How to Operate your Vehicle ................................................................12
• Circuit Diagram .....................................................................................13
Maintenance and Service
• General .................................................................................................14
• Charging the Drive Battery ...................................................................15
• Battery Replacement, Disposal ............................................................16
• Battery Storage .....................................................................................17
Troubleshooting .............................................................................18
Warranty
• Limited Warranty ................................................................................... 19
SPECIFICATONS:
Suitable Age 3+ Years
Load Capacity 65 lbs (30kgs)
Charger Input 120v - 60hz
Output: See charger for details
Drive Motor 6v 30w
Drive Battery 6v 7Ah
Important! Before using the unit for the fi rst time the battery needs to be charged
for at least 8 to 12 hours - no more than 20 hours. Only an adult who has read and
understands the safety warnings should handle, charge or recharge of the battery
(see Maintenance).
19
Warranty
Limited Warranty
Your purchase includes the following limited warranty, which is in lieu of all other ex-
press warranties. This warranty is extended to the initial purchaser only. Warranty
registration is not required. This warranty gives you specifi c legal rights: you may
have other rights, which vary from state to state.
The Vehicle and its component parts are under warranty to be free from faulty mate-
rials and workmanship from the date of the original purchase as follows:
• Drive Battery - 30 days
• Electronics - 90 days
• All other Components - 6 months
• All parts are subject to the Conditions of Warranty below.
Conditions Of Warranty
• It is the responsibility of the original consumer to ensure all parts included in the
factory sealed carton are properly installed and that all functional parts are work-
ing properly.
• This Vehicle has been designed for general transportation and recreational use.
This warranty shall become immediately null and void if you do any of the follow-
ing:
• Rent the Vehicle
• Sell the Vehicle
• Give away the Vehicle
• Use Vehicle in ways confl icting with use and warnings described in this
manual.
• The user assumes all risk of personal injuries, damage to, or failure of the Ve-
hicle and any other losses if the Vehicle is altered in any way or if the Vehicle is
used for stunt riding, ramp jumping, acrobatics or similar activities, or is towed by
another person or vehicle.
• This warranty does not cover ordinary wear and tear, damage caused by improp-
er storage of the Vehicle, shipping damage, damage caused either accidentally
or deliberately by you or another, and damage caused as a result of using the
Vehicle other than for its intended purpose.
How do you get service?
Contact Huffy Consumer Service.
See included list for Customer Contact information.
This product meets ASTM F963 and CPSIA requirements for electric
vehicles.
18
Problem Possible Cause Solution
Vehicle does not run Battery low on power Recharge battery (see Battery: Recharge
interval and time)
Thermal fuse has tripped Let Fuse reset (approx. 5 minutes)
Battery connector or wires are
loose
Check that the battery connectors are fi rmly
plugged into each other. If wires are loose
around the motor call Customer Service.
Battery is dead Replace battery (see Battery: Replacement
and Disposal)
Electrical system is damaged Call Customer Service.
Motor is damaged Call Customer Service.
Vehicle does not run
very long
Battery is under charged. Check that the battery connectors are fi rmly
plugged into each other when recharging (see
Battery: Recharge interval and Time)
Battery is old Replace battery (see Battery: Replacement
and Disposal)
Vehicle runs sluggishly Battery low on power Recharge battery (see Battery: Replacement
and Disposal)
Battery is old Replace battery (see Battery: Replacement
and Disposal)
Vehicle is overload Reduce weight on vehicle (see user require-
ments and Safety Warnings)
Vehicle is being used in harsh
conditions
Avoid using vehicle in harsh conditions (see
User Requirements and Safety Warnings)
Vehicle will not run
when foot pedal is
pressed and shift lever
is in the forward or
backward position
Poor contact of wires or
connectors
Check that the battery connectors are fi rmly
plugged into each other. If wires are loose
around the motor call Customer Service.
“Dead Spot” on motor A dead spot means the electric power is not
being delivered to the terminal connection
and the vehicle needs repair. Call Customer
Service.
Diffi cult shifting from
forward to reverse or
vice-versa
Attempting to shift while the
vehicle is in motion
Completely stop the vehicle and shift (see Use:
Manual Operation)
Loud grinding or click-
ing noises coming from
motor or gear box
Motor or gears are damaged Call Customer Service.
Drive Wheel is partially
engaged
Check drive wheel - to motor engagement.
Battery will not re-
charge
Battery connector or adapter
connector is loose
Check that the battery connectors are fi rmly
plugged into each other.
Charger not plugged in
Charger is not working Check that the battery charger is plugged into
a working wall outlet.
Battery is dead Replace battery.
Charger feels warm
when recharging
This is normal and not a
cause for concern
If excessively hot, unplug and replace.
Troubleshooting Guide:
Troubleshooting
3
Safety & Warnings
Before using the vehicle the child must understand the controls and safety issues.
They must also demonstrate the capability to handle the vehicle and operate its con-
trols.
It is the responsibility of the adult to educate the child, determine if they are fi t to
operate the vehicle, and supervise use.
Here are basic, common sense safe riding practices you should read aloud to your
child and anyone who may use the vehicle:
• An adult must always supervise a child that is using the vehicle.
• Always sit in the seat when using the vehicle. Do not stand on side boards.
• This vehicle is unsuitable for children under 3 years. The user must be 3+ years, and
weigh no more than 65 lbs (30kgs).
• This product contains small parts that are for adult assembly only. Keep small chil-
dren away when assembling. Remove and dispose of all protective material and poly
bags before assembly. Be sure to remove all packaging materials and parts from
underneath the vehicle body.
• Always use the vehicle in a safe, secure environment with continuous adult supervi-
sion.
• Body parts such as hands, legs, hair and clothing can get caught in moving parts.
Never place a body part near a moving part or wear loose clothing while using the
vehicle. Always wear shoes when using vehicle.
• Use on fl at, smooth paved surfaces only.
• Using the vehicle on or near streets, motor vehicle, drop-offs such as: steps, water
(swimming pools), sloped surfaces, hills, wet areas, fl ammable vapors, in alleys, at
night or in the dark could result in an accident.
• Do not use the vehicle in unsafe conditions such as snow, rain, loose dirt, mud sand
or fi ne gravel. This may result in unexpected action such as tip over and skidding.
• This vehicle has no brakes. Motor friction will gradually stop the unit.
• Do not use the vehicle in an unsafe manner. Examples include but are not limited to:
• Pulling the vehicle with another vehicle or similar device.
• Allowing more than one rider.
• Pushing the vehicle.
• Traveling at an unsafe speed.
• There are additional hazards of using the vehicle in areas other than private grounds.
• Not to be used in traffi c.
• The vehicle shall be used with caution since skill is required to avoid falls or colli-
sions.
• Do not overload the vehicle.
• Do not tow anything behind the vehicle.
• Do not drive up steep slopes.
Warnings continued >>
WARNINGS
