Page 1/16
Document ID: USM-0S0-MM3
Revision: 1.11
Made in U.S.A. www.iPGARD.com 1-800-284-2131
USER MANUAL
Advanced 2/4/8-Port DisplayPort Secure KVM Switch
SDPN-2S 2-Port Secure DisplayPort KVM with Audio
SDPN-2D 2-Port Secure Dual-Head DisplayPort KVM with Audio
SDPN-2S-P 2-Port Secure DisplayPort KVM with Audio and CAC Support
SDPN-2D-P 2-Port Secure Dual-Head DisplayPort KVM with Audio and CAC Support
SDPN-4S 4-Port Secure DisplayPort KVM with Audio
SDPN-4D 4-Port Secure Dual-Head DisplayPort KVM with Audio
SDPN-4S-P 4-Port Secure DisplayPort KVM with Audio and CAC Support
SDPN-4D-P 4-Port Secure Dual-Head DisplayPort KVM with Audio and CAC Support
SDPN-4Q-P 4-Port Secure Quad-Head DisplayPort KVM with Audio and CAC Support
SDPN-8S 8-Port Secure DisplayPort KVM with Audio
SDPN-8S-P 8-Port Secure DisplayPort KVM with Audio and CAC Support
Release Date: July 3rd, 2018
TABLE OF CONTENTS
3
4
4
4
5
11
11
12
12
13
14
14
14
15
TECHNICAL SPECIFICATIONS___________________________________________________________
WHAT’S IN THE BOX?_________________________________________________________________
SECURITY FEATURES_________________________________________________________________
SDPN FRONT AND REAR______________________________________________________________
INSTALLATION_______________________________________________________________________
CAC INSTALLATION: COMMON ACCESS CARD, SMART CARD READER__________________________
CAC PORT CONFIGURATION____________________________________________________________
AUDITING: Dumping the Event Log via User Menu Options___________________________________
RESET: Restore Factory Default_________________________________________________________
LED’s BEHAVIOR_____________________________________________________________________
SYSTEM OPERATION__________________________________________________________________
TROUBLESHOOTING__________________________________________________________________
TECHNICAL SUPPORT_________________________________________________________________
LIMITED WARRANTY STATEMENT_______________________________________________________
Advanced 2/4/8-Port DisplayPort Secure KVM Switch 2
TECHNICAL SPECIFICATIONS
Advanced 2/4/8-Port DisplayPort Secure KVM Switch 3
VIDEO
Format DisplayPort
Host Interface
SDPN-2S/SDPN-2S-P (2) DisplayPort 20-pin (female)
SDPN-2D/SDPN-2D-P/
SDPN-4S/SDPN-4S-P
(4) DisplayPort 20-pin (female)
SDPN-4D/SDPN-4D-P/
SDPN-8S/SDPN-8S-P
(8) DisplayPort 20-pin (female)
SDPN-4Q-P (16) DisplayPort 20-pin (female)
User Console
Interface
SDPN-2S/SDPN-2S-P/
SDPN-4S/SDPN-4S-P/
SDPN-8S/SDPN-8S-P
(1) DisplayPort 20-pin (female)
SDPN-2D/SDPN-2D-P/
SDPN-4D/SDPN-4D-P
(2) DisplayPort 20-pin (female)
SDPN-4Q-P (4) DisplayPort 20-pin (female)
Max Resolution 3840x2160 @ 30Hz
DDC 5 volts p-p (TTL)
Input Equalization Automatic
Input Cable Length Up to 20 ft.
Output Cable Length Up to 20 ft.
USB
Signal Type USB 1.1 and 1.0 Keyboard and Mouse only. USB 2.0 for CAC connection.
Type A to B
SDPN-2S/SDPN-2D (2)
SDPN-2S-P/SDPN-2D-P/SDPN-4S/SDPN-4D (4)
SDPN-4S-P/SDPN-4D-P/SDPN-4Q-P/SDPN-8S (8)
SDPN-8S-P (16)
User Console Interface
(2) USB Type-A for keyboard and mouse connection only
(1) USB Type-A for CAC connection (P models only)
AUDIO
Input (2)/(4)/(8) Connector Stereo 3.5mm Female
Output (1) Connector Stereo 3.5mm Female
POWER
Power Requirements
12V DC, 2A (minimum) power adapter with center-pin positive polarity.
Quad head models require a 12V DC 3A (minimum) power adapter with
center-pin positive polarity.
ENVIRONMENT
Operating Temp 32° to 104° F (0° to 40° C)
Storage Temp -4° to 140° F (-20° to 60° C)
Humidity 0-80% RH, non-condensing
CERTIFICATIONS
Security Accreditation &RPPRQ&ULWHULD9DOLGDWHG7R1,$33URWHFWLRQ3URÀOH3669HU
OTHER
Emulation USB 1.1 and USB 2.0 Compatible
Control Front Panel Buttons

Product Specifications
