KLS-601
MagBlaster
Congratulations on the purchase of your new KlipXtreme KLS-601 loudspeaker system with
wireless technology. We invite you to visit www.klipxtreme.com to find out more about this
audio system and other new and exciting products.
• 2000-watt PMPO of distortion free, and powerful stage quality sound that fills the scene
• Two powerful 8in subwoofers that stream every bass note and deliver incredible audio performance
• Built-in 3.600mAh rechargeable battery which makes the speaker autonomous for up to 9 hours
2
• Convenient 12V external DC input for additional battery charge and extra playback time
• Works with your favorite Bluetooth
®
v5.0-enabled devices
1
• TWS (True Wireless Stereo) capability, designed to connect and stream audio through two
identical units simultaneously
• LED illumination, with on/off capability
• Equalizer enables to select different sound effects (normal, rock, pop, jazz, classical, and country)
• Includes a high-quality wireless microphone and a convenient remote control
• Additional 1/4in (6.5mm) input for wired microphone
• Integrated audio playback with USB and microSD™ memory card slots
• Built-in heavy-duty handle and wheels that make it extremely portable
• Practical slot for placing tablet or smartphones makes it easier to stream music from these
mobile devices
• LED display showcases modes and convenient remote control allows to add sound effects
• Built-in radio tuner to listen to your favorite stations
• One-year warranty
• Loudspeaker system (1)
• Wireless microphone with batteries (1)
• Power cord (1)
• Auxiliary cable (1)
• Remote control with batteries (1)
• User manual (1)
Unpack your unit carefully. We recommend that you keep the box and all original packing
materials, in case you wish to store the unit, or if you ever need to return it for service.
English
III. Product overview
Front and side view
I. Introduction
Main features
II. Package content
1. LED display
2. Subwoofers x2
3. Metallic grid
4. Handle (on back panel)
5. Rubber feet and wheels
6. LED lights
1
4
2
5
6
3
Top panel
Control Description
Control Description
1. DC12V input
2. LED lights switch
3. Power (On/Off switch)
Charging input for wired charging with a 12V cable (not included).
Turns LED lights on or off.
Press this switch to turn the unit on/off.
Adjusts the treble (high) frequencies of the speaker.
Controls the overall audio level from all inputs. Turn it counterclockwise to
lower the volume, or clockwise to increase the audio coming from the
speaker.
The volume can also be controlled directly from each of the sources
connected to the speaker.
Note: The unit has a built-in antenna to pick up the signal for the FM mode.
4. Volume knob
5. Treble knob
Enables audio playback from music files stored in a USB memory stick or
in a microSD™ card.
6. MicroSD™ card
slot/USB port
This jack accepts an auxiliary cable. Once the cable is plugged, it starts
playing right away. You can't skip or pause music from the speaker only
through the connected device.
7. Aux input
Press this button once to make the microphone sound louder than the
music. Press it once again to make the music sound at the same volume
level than the microphone.
9. Microphone
priority button
Press and hold this button to record voice from the microphone. To stop
it press this button once. It will automatically play the recording. Only the
microSD™ and USB modes can record.
In Bluetooth
®
, USB, and microSD™ mode, briefly press this button to
select the previous track.
In FM mode, briefly press this button to go to the previous radio station.
This feature is not available in auxiliary mode.
Press it to play and pause audio in the Bluetooth
®
, USB, or microSD™
modes.
In FM mode it scans all the stations.
Enables to pair two speakers of the same model through TWS.
In Bluetooth
®
, USB, and microSD™ mode briefly press this button to
select the next track.
In FM mode briefly press this button to go to the next radio station.
This feature is not available in auxiliary mode.
10. Record button
11. Prev. button
12. Play/pause/
TWS button
13. Next button
Press this button briefly to toggle through the different audio sources
available: Bluetooth
®
, USB, microSD™, Aux, and FM.
The corresponding mode symbol will be showcased on the display when
the selected source is playing. As there is no default mode assigned, the
system starts playing automatically the last media source inserted.
14. Mode button
LED light that turns red when charging the speaker. It turns off when the
speaker is fully charged.
15. Charging indicator
This jack accepts the input from a wired microphone.
16. MIC input
Adjusts the bass (low) frequencies of the speaker.
17. Bass knob
Controls the audio level of the wireless and wired microphones actively
connected to the speaker. When adjusting the microphone volume, the
indication appears on the LED display
Adjust this knob to control how much of an echo effect is applied to the
signal from the microphone actively connected to the speaker.
18. MIC volume knob
19. MIC ECHO knob
Plug the power cord to charge the speaker. When the speaker is charging
the LED indicator glows red. Once it is fully charged, the LED indicator
turns off.
20. AC 110-240V
charging input
Display that showcases the modes, radio stations, and volume level.
8. LED display
8 9
1 2
10
11 12 13 14
15 16
17
18
19
7
6
5
4
3
20
