Best Connectivity
Features:
» Universal antenna wall socket for Sat/TV/Radio
» For digital channel and back channel
» With DC pass
» Frequency: 5-2400MHz (SAT)
» Impedance: 75 Ohm
» With cover and frame
» Color: RAL9003
Specification:
Insertion Loss (IN-OUT)
5-40MHz
40-1000MHz
1000-2150MHz
2150MHz-2400MHz
-
Insertion Loss (IN-RADIO)
0.15-26MHz
8 8 -110 M H z
111-125 M Hz
126-139MHz
-
2.0dB
2.5dB
-
Insertion Loss (IN-TV)
5-30MHz
46-68MHz
139-150MHz
151-862MHz
2.5dB
2.5dB
2.5dB
2.5dB
2.5dB
Insertion Loss (IN-SAT)
950-1750MHz
1750-2150MHz
2150-2400MHz
2.5dB
2.5dB
3.0dB
Return Loss
Input
Output
TV
Radio
SAT
8dB
-
8dB
8dB
7dB
Art. No.: CA1003
Antenna-Wall-Socket
for SAT/TV/Radio
Best Connectivity
Art. No.: CA1003
Antenna-Wall-Socket
for SAT/TV/Radio
Package Content:
» 1 x Antenna-Wall-Socket for SAT/TV/Radio
Package Information:
» Packing Dimension: 80 x 80 x 45mm
» Packing Weight: 0.11kg
» Carton Dimension: 450 x 250 x 370mm
» Carton Q‘ty: 100pcs
» Carton Weight: 12kg
