Overview
Ove rview
The Makita SK105D/SK105GD is a self-levelling
cross-line laser. It is a reliable precision laser for
any kind of tasks like levelling, plumbing, trans-
fering and setting out right angles.
It supports you on job side with two crossing ver-
tical and horizontal lines.
1Window of vertical line
2Window of horizontal line
3Status LED
4ON / Set key
5Levelling lock / Transportation lock
6Battery (optional)
7Tripod thread 1/4"
8DC jack
There are 2 different types available:
l SK105D (red laser)
l SK105GD (green laser)
On all images in this document only the
SK105D is shown.
Makita SK105D/SK105GD
2
Technical data
Te chn ica ld ata
Makita SK105D/SK105GD
3
Description SK105D SK105GD
Beam direction/fan angle Vertical / >160°, Horizontal / >180°
Range* 25 m (82 ft) 35 m (115 ft)
Range* with receiver 80 m (262 ft)
Levelling accuracy ±0.3 mm/m = ±3.0 mm @ 10m (±0.004 in/ft = ±0.12 in @ 33ft)
Horizontal/Vertical line accuracy ±0.3 mm/m (±0.004 in/ft)
Self-levelling range ± 4 °
Self-levelling time < 3 s
Out-of-level warning Yes - blink lines every 5 s
Levelling system Automatic pendulum lockable
Laser type 635 ± 5 nm, Class 2 (acc. IEC 60825-1) 525 ± 5 nm, Class 2 (acc. IEC 60825-1)
Battery cartridge BL1015 / BL1016 / BL1020B / BL1021B / BL1040B / BL1041B
Operating time with Li-Ion battery
(2 beam)
15 h (BL1015/BL1016)
20 h (BL1020B/BL1021B)
40 h (BL1040B/BL1041B)
7 h (BL1015/BL1016)
10 h (BL1020B/BL1021B)
20 h (BL1040B/BL1041B)
Net weight 0.46 kg
Weight with Li-Ion battery 0.67 kg – 0.84 kg
Power supply Makita battery cartridge / USB adapter
Rated voltage D.C. 10.8 V - 12 Vmax, D.C. in 5 V
Dimensions (L x W x H) 112 x 61 x 102 mm (4.41 x 2.40 x 4.01 in)
Operating temperature (instrument) -10…+50 °C (+14…+122 °F)
Storage temperature (instrument) -25…+70 °C (-13…+158 °F)
Laser line width at 5m distance < 2 mm (<0.08 in)
Tripod thread 1/4’’ (+ 5/8’’ with adapter)
Pulse power for receiver Yes, auto
* depending on lighting conditions
