The Most Musical Sound
8 x 100W per channel Four-Zone Distribution Amplier with HEOS® Built-in
Four-Zone Distribution Amplier
MODEL M4
• 8 x 100W Amplication (8 ohm 20-20kHz) 0.05% THD
• 192/24 FLAC, ALAC, WAV, DSD
• Stereo RCA in x4, Optical x2, Ethernet x2, USB-A x4
• HEOS®, AirPlay2, Dolby Digital
• Stereo preouts per zone or four subwoofer outputs, one per zone
• Convert preout to subwoofer out with High Pass and Low Pass Filters
• TV Sound Grouping
• Marantz Musical Digital Filtering (MMDF)
• 12V trigger out per zone and Bridge mode
• Perfectly sized for rack mounted design and active cooling,
rack kit included
Audio Options
Channel Assignments Stereo (Default), Dual Mono
Volume Limit 80-100%
Balance -15dB to +15dB
Adjustable High Pass / Low Pass Filters 40-250 Hz / 40-120 Hz
EQ Bass, Treble -5dB to +5dB
Sound Modes
Stereo, Direct, Virtual,
Dialog Enhancer, Night Mode
TV Sound Grouping Yes
Audio Format Support
Decoding Dolby Digital, LPCM, DSD
Stereo PCM / Multi-channel PCM Yes / Yes
Stereo File Formats (HEOS® network share or USB)
WMA: up to and including 192 kbps
AAC & MP3: up to and including
320 kbps
WAV, ALAC, FLAC: up to and
including 24-bit/192kHz
DSD: 2.8 MHz, 5.6MHz
Audio Inputs / Outputs
Loudspeaker Binding Posts 4-way binding posts
Digital Inputs TOSLINK (2)
Analog Inputs RCA L/R (4)
Preouts RCA L/R (4)
Subwoofer Out RCA Mono (4) (selectable)
Technical Specications
MODEL M4
Networking & Control
Wired Connectivity Ethernet (2)
Wireless Connectivity N/A
IR Input N/A
IR Learning N/A
Control System Compatibility via TCP/IP Crestron, Control4, AMX
HEOS® App iOS, Android, Kindle Fire
Trigger Output DC 12V Yes (4)
Music Services and Sources
Music Services Supported (HEOS®, subject to change and local availability)
Pandora, Spotify, TuneIn,
SiriusXM, Amazon Music, Tidal,
Tidal HiRes, iHeartRadio, Deezer,
Deezer HiFi, Mood:Mix, Sony
Hi-Res, AWA, QPlay, SoundCloud
Music stored on mobile device Yes (iOS, Android or Kindle Fire)
NAS (Network Attached Storage) Network share
USB Storage Device Playback
Yes (4) (FAT32, NTFS formatted
drives)
General
Product Color Black
User Interface
Reset button, Front power button,
Rear power switch
Dimensions (W x D x H) Inches 16.34 x 4.17 x 17.4
Dimensions (W x D x H) mm 415 x 106 x 442
Weight (lbs)
Weight (kg)
Design and specifications are subject to change by Marantz without notice.
www.marantz.com
Amplier
Power Amplier Rated output & THD (8 ohm)
8 X 100 W (8 Ω/ohms, 20 Hz to 20
kHz, T.H.D. 0.05 %)
Power Amplier Rated output & THD (4ohm)
8 X 125 W (4Ω/ohms, 1 kHz,
T.H.D. 0.1%)
Frequency Response 20 Hz to 20 kHz : ±1 dB
Connected loudspeaker Impedance 4 – 16 Ω/ohms
Streaming Technologies
Bluetooth Receive N/A
Bluetooth Transmit N/A
AirPlay AirPlay 2
Spotify Spotify Connect
Product Specifications
| Brand: | Marantz |
| Category: | Receiver |
| Model: | MODEL M4 |
