Page 1/7
Broadcast A/V Division
AR-AM4-BG-2
Multichannel Analog Audio Monitor
User Manual
[Firmware Version 0.43]
AR-AM4-BG-2 Manual
www.marshall-usa.com2 3
Table of Contents
2. Package Contents
3. Front Panel Description
4. Control Button Detail
5. Rear Panel Description
6. Operation
7. Metering and Indicators
8. Software - Control App
9. Serial Connection
10. Operation
11. Updating
12. Specifications
Warranty
1. Features
03
04
05
05
06
06
07
08
09
10
11
12
03
High Performance Audio
Matches or exceeds many larger 2RU designs
Enough “punch” for the noisiest server rooms
Multiple Inputs
4 Analog XLR Balanced – 4 Inputs x 2 Channels Each
Outputs
1 Analog XLR Balanced - 2 Channel
LED VU Display
Provides active indication of audio input activity
Controllable via RS-232 Serial
Remote control application downloadable from Marshall website
Select sources, mute, solo, volume, etc.
Compact 1RU Design Saves Rack Space
Minimum size
Low power consumption, low heat into rack
Compact size which does not compromise audio volume
AR-AM4 Main Chassis
12-volt Universal Power supply (120/240V – 50/60Hz)
Remote Control Application (free download from website)
1. Features
2. Package Contents
AR-AM4-BG-2 Manual
www.marshall-usa.com4 5
1. Speakers
Provides sound from two channels except when Solo buttons are pressed
2. Headphone Jack
3. Volume Knob / Mute Button
Turn the knob to adjust the sound level out of both speakers
Press in on the knob to instantly mute the speaker
4. Headphone Jack
Designed to accept stereo headphones with 3.5mm plug
5. Input and Solo Left/Right Select Buttons
Select either channel for monitoring from both speaker
6. LED VU Meter Display
7. LED Indicator Lights
Phase – Indicates audio in-phase / out-of-phase conditions
Mute – Indicates when speakers have been muted
8. Balance Knob
Select either speaker or adjust balance between them
3. Front Panel Description
1. Input Select
Press one of these four buttons to monitor the corresponding input
2. Solo Left & Solo Right
Press isolate either the left or right channel only
Note: Sound will come out of both speakers when Solo is selected but will originate from a
single source.
1. Power Switch
2. 12-Volt DC Power Input – Coaxial, Center Positive
3. RS-232 Serial Control 9-pin D-Sub Port and Loop Out
4. Analog Balanced XLR +4dBu Output Pair (2 channels)
5. Four Analog Balanced XLR +4dBu Input Pairs (8 channels)
4. Control Button Detail
5. Rear Panel Description
