Broadcast A/V Division
VDA-104-3GS-2
1x4 3G/HD/SD-SDI Re-clocking
Distribution Ampliļ¬er
User Manual
VDA-104-3GS-2 Manual
www.marshall-usa.com2 1
Table of Contents
Safety Instructions
The VDA-104-3GS-2 1x4 3G/HD/SD-SDI Re-clocking Distribution Ampliļ¬er has been tested
for conformance to safety regulations and requirements and has been certiļ¬ed for international
use. However, like all electronic equipment, the VDA-104-3GS-2 should be used with care. Please
read and follow the safety instructions to protect yourself from possible injury and to minimize the
risk of damage to the unit.
ā¢ Follow all instructions and warnings marked on this unit.
ā¢ Do not attempt to service this unit, except where explained in this manual.
ā¢ Provide proper ventilation and air circulation and do not use near water.
ā¢ Keep objects that might damage the device and assure that the placement of this unit is on a
stable surface.
ā¢ Use only the power adapter and power cords and connection cables designed for this unit.
ā¢ Do not use liquid or aerosol cleaners to clean this unit. Always unplug the power to the device
before cleaning.
1. Introduction
2. Features
3. Package Contents
4. Speciļ¬cations
5. Panel Descriptions
6. Hardware Installation
7. Connection Diagram
Safety Instructions
02
02
02
03
04
05
05
01
VDA-104-3GS-2 Manual
www.marshall-usa.com2 3
1. Introduction
2. Features
The VDA-104-3GS-2 receives one SDI input, perfectly duplicates it, and re-transmits four SDI
outputs for real time multi-viewing. It is a reliable video device splitting a SDI, HD-SDI, or 3G-SDI
video source to four SDI compliant displays at the same time. Besides, built-in re-clocking &
equalization features provide the best performance for SDI distribution ampliļ¬er.
ā¢ 3G/HD/SD triple-rate distribution
ā¢ Four separately buffered and re-clocked outputs
ā¢ Supported SDI format
Ā» 3G-SDI (SMPTE 424M, 425M level A,B up to 2.97 Gbps)
Ā» HD-SDI (SMPTE 292M, 296M up to 1.485 Gbps)
Ā» SD-SDI (SMPTE 259M, up to 270 Mbps)
ā¢ Cable equalization (Belden 1694A) and signal retiming
ā¢ Video bandwidth: 2.97Gbps, 2.97/1.001Gbps
ā¢ Automatic detection of 3G/HD/SD-SDI signals
ā¢ Dual color LED indication of input lock and rate
ā¢ Passes all ancillary data
ā¢ Provides automatic cable equalization
Ā» [3G-SDI]* >120m (394ft)
Ā» [HD-SDI] >200m (656ft)
Ā» [SD-SDI] >300m (984ft)
ā¢ Re-clocks SDI signals for cascading and thus longer transmission
ā¢ Inter-locked power supply for better ļ¬xedness
Note: The cable length depends on the characteristics and quality of the cables.
3. Package Contents
ā¢ 1x VDA-104-3GS-2
ā¢ 1x 5V power adapter
ā¢ 1x Marshall Thank you Card
4. Speciļ¬cations
Model Name VDA-104-3GS-2
Technical
SDI standards SD/HD/3G-SDI
Auto 3G/HD/SD detection Yes
Supported protocols SMPTE 259M, SMPTE 292M, SMPTE 424M, SMPTE425M
Video bandwidth [2.97Gpbs & 2.97/1.001Gbps]
Data rates 270 / 1483 / 1485 / 2970 Mbps
Output impedance 75
Re-clocking function Yes
Cable equalization [3G-SDI] >120m (394ft) / [HD-SDI] >200m (656ft) / [SD-SDI] >300m (984ft)
Audio support Yes
RP-198 pathological
patterns
Immune
PCB stack-up 4-layer board [impedance control ā differential 100 ; single 50 ]
Input 1x BNC [SDI]
Output 4x BNC [SDI]
BNC connector 75 inter-locked socket
Eye pattern characteristics
[HD]
Amplitude: Within 800mV Ā±3% (<10%) Long time jitter: 0.195 UI (<1.0 UI)
Rise overshoot: Less than 2% (<10%) Timing jitter: 0.195 UI (<1.0 UI)
Fall overshoot: Less than 2% (<10%) Alignment jitter: 0.127 UI (<0.2 UI)
Mechanincal
Housing Metal enclosure
Dimensions
[L x W x H]
Model 80.5 x 41.4 x 24.2mm [3.2ā x 1.6ā x 1ā]
Package 175 x 128 x 134mm [6.9" x5" x5.3"]
Carton 662 x 366 x 290mm [2'2" x 1'2" x 1']
Weight
Model 174g [0.4 lbs]
Package 440g [0.9 lbs]
Fixedness Inter-locked power supply
Power supply 5V 2A DC
Power consumption 0.85 Watts [max]
Operation temperature 0~40Ā°C [32~104Ā°F]
Storage temperature -20~60Ā°C [-4~140Ā°F]
Relative humidity 20~90% RH [no condensation]
Note: The measurement results are from Tektronix WFM-7120 with SDI through 1m (3.3ft) long
Belden 1694A
Product Specifications
