M OSAIC
TM
user’s manual
M ARTIN L OGAN
the loudspeaker technology company
®
2 Contents
CONTENTS
Contents . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2
Installation in Brief . . . . . . . . . . . . . . . . . . . . . . . .3
Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4
Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5
Signal Connection
Break-In
Placement . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6
Listening Position
The Wall Behind the Listener
The Wall Behind the Speakers
The Side Walls
Experimentation
Final Placement . . . . . . . . . . . . . . . . . . . . . . . . . . . .7
The Extra “Tweak
Enjoy Yourself
Room Acoustics . . . . . . . . . . . . . . . . . . . . . . . . . . .8
Your Room
Terminology
Rules of Thumb
Dipolar Speakers and Your Room . . . . . . . . . . . . . . .9
Solid Footing
Home Theater . . . . . . . . . . . . . . . . . . . . . . . . . .10
ATF (Advanced Thin Film) . . . . . . . . . . . . . . . . . .11
Frequently Asked Questions and Troubleshooting .12
General Information . . . . . . . . . . . . . . . . . . . . . .13
Specifications
Warranty and Registration
Service
Glossary of Audio Terms . . . . . . . . . . . . . . . . . . .14
Installation in Brief 3
INSTALLATION IN BRIEF
We know you are eager to hear your new Mosaic loud-
speaker, so this section is provided to allow fast and easy
set up. Once you have it operational, please take the time to
read, in depth, the rest of the information in this manual. It
will give you perspective on how to attain the greatest pos-
sible performance from this most exacting transducer.
If you should experience any difficulties in the setup or
operation of your Mosaic speaker, please refer to the
Operation or Placement sections of this manual.
Should you encounter a persistent problem that cannot be
resolved, please contact your authorized MartinLogan dealer.
They will provide you with the appropriate technical analysis
to alleviate the situation.
WARNING!
•Refer servicing to a qualified technician.
•To prevent fire or shock hazard, do not
expose this module to moisture.
•Turn amplifier off should any abnormal
conditions occur.
•Do not drive speaker beyond its rated power.
Step 1: Unpacking
Remove your new Mosaic speaker from the packing.
Step 2: Placement
Place the Mosaic near the desired location. Please see the
‘Placement’ section (page 6–7) for more details.
Step 3: Signal Connection
Use the best speaker cables you can. Higher quality cables,
available from your specialty dealer, are recommended
and will give you superior performance. Spade connectors
are suggested for optimum contact and ease of installation.
Attach your speaker cables to the signal input section on
the rear panel. Be consistent when connecting speaker leads
to the terminals on the back of the Mosaic. Take great
care to assign the same color to the (+) terminal on both
the speaker and the amplifier. Please see the ‘Operation
section (page 5) for more details.
Step 4: Listen and Enjoy
Now, you may turn on your system and enjoy!
The lightning bolt flash with arrowhead symbol within
an equilateral triangle is intended to alert the user to
the presence of uninsulated “dangerous voltage” within
the product’s enclosure that may be of sufficient mag-
nitude to constitute a risk of electric shock.
The exclamation point within an equilateral triangle is
intended to alert the user to the presence of important
operating and maintenance (servicing) instructions in
the literature accompanying the appliance.
