Maruyama MD155DX Manual

Read below 📖 the manual in Italian for Maruyama MD155DX (32 pages) in the Not categorized category. This guide has been helpful for 20 people and has been rated 4.5 stars on average by 2 users

Page 1/32
MD155DX / MD155 / MD155DX-CA :
MIST DUSTER
MD157D / MD159D : DUSTER
Maruyama U.S., Inc.
3570 Shelby Lane
Denton, TX 76207 U.S.A
P.O. Box 2107
Denton, TX 76202 U.S.A
Phone 940-383-7400
www.maruyama-us.com
120712-07 09.08 TAP/M
1
1.
2.
3.
4.
5.
6.
7.
8.
9.
10.
11.
12.
13.
14.
15.
16.
17.
18.
19.
Foreword
Manual Safty Symbols
Limited Warranty Statement
WARNING
Safty Precautions for Applying Chemicals
Assembly Instructions
Assembling Adjustment of Mist Nozzle
Preparations for Starting
Operating Instructions
Operation For MD155DX / MD155
Preparations For Duster Attachment And MD157D / MD159D
Operation For Duster
Performance Graph For Discharge (for Duster)
Regular Maintenance
Storage
Emission Control Information
Maintenance
Trouble shooting
Specication
2
2
3
6
7
8
9
10
12
14
15
17
19
24
25
26
28
29
30
TABLE OF CONTENTS
TOPIC PAGE
30
SPECIFICATIONS
Models
MD155DX
MD155DX-CA
MD155 MD157D MD159D
Dimensions L W H
15.9 20.5 26.4in.
(405 520 670mm)
16.3 20.5 29.1in.
(415 520 740mm)
24.3 lbs. (11kg)
25.4 lbs. (11.5kg)
Kawasaki/2-Stroke Air cooled
TEX 45D
40.2 cc
Electric
All position diaphragm
NGK BPMR7A
0.52 gal (2.0 lit)
50:1
FLEXIBLE PIPE, SWIVEL PIPE,
STRAIGHT PIPE, BENT PIPE, MIST NOZZLE for MD155DX/MD155
Standard Parts
Option Parts
3.38 gal (13 lit)
5.98 gal (23 lit)
Plate fan
0.92 gal/min (3.5 /min)
13.3 b/min (6kg/min)
44.4 b/min (2kg/min)
Standard Parts
Dry Weight
Engine Type
Displacement
Gnition System
Carburetor
Spark Plug
Fuel Tank Capacity
Fuel Mixture:
Using Maruyama 50:1
2-Cycle Engine Oil or any
quality 2-cycle engine oil
designed for use in
air-cooled, high performance
2-cycle engines.
Attachments (Standard)
Duster Attachments
Chemical Tank Capacity
Fan Type
Maximum discharg volume
Liquid
Powder
Granular
The specication may be changed for product improvement, without prior notice.
Non Liquid
Powder 13.3 bs/min (6kg/min)
Granular 44.4 bs/min (20kg/min)
29
TROUBLE SHOOTING
When engine fails to start:
There is fuel,
but spark plugs
fail to ignite.
There is fuel and
spark plugs ignite.
No fuel in the carburetor
Diagnoses Causes
Drawing too much fuel.
Engine fails to run smooth:
Diagnoses Causes
Air cleaner element is plugged up.
Air has entered fuel line joints.
Faulty spark plug gap.There is power at the terminal.
Faulty spark plug insulation.
Faulty TCI unit or broken wire.
A break or short in the igniton coil.
Bad mixture.Compression is good.
Faulty packing or tightening.
Spark plugs not tightened properly.Compression is bad.
Piston rings are sticking.
No fuel in the tank.
Fuel valve is faulty or fuel tank air
vent is plugged.
Faulty choke lever.
Compression is good and
there is no miss re.
No power
Carbon build-up on cylinder muî™…er.
Carbon piled up, overloaded
operation.
Engine overheated
Faulty spark plugs.
Plugged cylinder or coolant lines.
Carburetor not adjusted properly or
Poor gasoline oil quality.
Slow acceleration
Carbon pile-up.
Carburetor not adjusted properly.
Faulty spark plugs.
Inaccurate explosion
Faulty magneto or internal short.
Overheated cylinders.
Overload operation.
Faulty mixture or incorrect ratio.
Engine doesn't sound right
Internal engine damage.
Burnt spark plugs.
Short in cable.
Bad mixture or piston ring wear.
Compression is bad, and
there is miss re.
Fuel is too low (mixture is too thin)
Faulty mixture, not enough mixture.
Marks on cylinder, cracks in the
piston head.
Fuel channels in the carburetor are
plugged.
Lines are bent.
No power at the terminal.
2
This symbol accompanied by the words WARNING and
DANGER calls attention to an act or condition that can lead to
serious personal injury to operator and bystanders.
FOREWORD
This Owner’s/Operator’s Manual is designed to familiarize the operator with the various features
and component parts of the equipment and to assist you with the assembly, operation and
maintenance of your new MIST DUSTER.
It is essential that any operator of this MIST DUSTER reads and understands this manual
before using the MIST DUSTER.
Important safety instructions will be identified by the following safety symbol:
Failure to comply with the instructions in this manual may result in serious injury or death.
For additional assistance, contact any local authorized Maruyama dealer or Maruyama U.S., Inc.,
3570 Shelby Lane Denton, TX 76207 U.S.A Phone(940)383-7400
Web:www.maruyama-us.com
MANUAL SAFETY SYMBOLS
Throughout this manual and on the product itself, you will find safety alerts and helpful, information
message preceded by symbols or key words. The following is an explanation of those symbols and
key words and what they mean to you.
