Marshall Electronics
Professional Audio Division
Phone: 310-333-0606 800-800-6608 Fax: 310-333-0688
www.mxlmics.com sales@mxlmics.com
603 PAIR
Instrument Microphones
Thank you for choosing the MXL 603 PAIR Condenser microphone. With
proper care, this mic will provide many years of satisfaction. To get the best
results, please take a few moments to read this manual.
Enjoy your microphone!
The MXL Team
General Characteristics
This microphone has a twenty millimetre gold-sputtered diaphragm and a
fixed cardioid pickup pattern. Condenser microphones are very
sensitive, readily revealing very subtle sonic details. They also tend to pick
up sounds outside the pattern more than some designs, which can lead to
powerful feedback if you are not careful. We strongly advise
experimentation with placement and isolation requirements with the gain
initially set low to avoid equipment (and ear) damaging surprises!
Contents
Unpack your MXL 603 PAIR microphone carefully and verify that all of the
following items are included:
• MXL 603 PAIR microphone
• Shock mount
• Aluminum flight case
If any of these items are missing or damaged, contact the company from
which you purchased the microphone.
Power Requirement
The MXL 603 PAIR requires 48V phantom power (± 4V). If no sound is
picked up by the microphone, make sure that the phantom power on your
mixer or separate power supply is switched on.
Microphone Cable
The microphone cable can have a profound effect on the sound of
any microphone. Even the finest microphone will sound poor if the
interconnect cable allows noise to enter or causes distortion and loss of
information. We recommend that you use the best microphone cable that
your budget will allow.
Care
Dust and foreign material can reduce the performance of a microphone
over time, so you should store the MXL 603 PAIR in its case when not in
use.
Shock Mount
The MXL shock mount can shift in shipment. Simply shift the nylon bands
to center the microphone in the assembly. Be sure that the wire clamp
Specifications
Type Condenser pressure gradient mic
Frequency Response 30Hz-20kHz
Capsule Size 22mm/.87 in.
Polar Pattern Cardioid
Impedance 200 ohms
Sensitivity 10mV/Pa
S/N Ratio 80dB (Ref. 1Pa A-weighted)
Equivalent Noise 18dB(A weighted IEC 268-4)
Max SPL for 0.5% THD 134dB
Power Requirement Phantom Power 48V ±4V
Current Consumption <3.0mA
Size 22mm x 135mm
Weight 130 g
Metal Finish Silver
Polar PatternFrequency Chart
does not rest on the chassis of the mount, as this impairs mechanical
isolation. Slide the mount all the way to the rim of the microphone for the
most secure hold.
Warranty
Marshall microphones are guaranteed against defects in materials and
workmanship for one year from date of purchase. Should you encounter
any problem with this unit, promptly contact the company from which
you purchased it from for assistance. The original dated sales receipt
will be necessary for any warranty claim. Do not send any unit directly
to us without prior authorization from our service department. Warranty
coverage is limited to repair or replacement (at our option) of the
microphone, and does not cover incidental damages due to use of this
unit, nor damage caused by accidental misuse of this product.
0
90270
180
8kHz
2kHz
AD091416a
