Page 1/36

Version June/2017

User Guide

www.nextodi.com

SD & Micro-SD 8 slot

CARD BATCHER

NCB-20-001

THE MULTIPLE CARD READER AND COPIER

Origin S. Korea

Manufacturer Nexto DI Co., LTD

Thank you for purchasing the NEXTO CARD BATCHER (NCB-20).

Please read this manual before using the Product. Follow operating instructions carefully to avoid damage on the

product, or personal injury.

Important safety notice

● The color or shape of the product you purchased may be a rather different from the representative image.

● NextoDI Co., Ltd. reserves the right to make improvements and/ or changes to the product and programs described in

this User's Guide at any time without notice.

● Do not drop, bump, shock, or expose the NCB-20 to vibration during video preview or while data is being transferred.

● Do not use near open flames (candles, stoves, grills, fires) or sparks (fireworks, welding torches).

● NextoDI does not offer and guarantee a service for data loss. For your important data, the additional separate backup

is recommended. For more secure data management, backup your data to an extra hard drive periodically. Under no

conditions is NextoDI Co., Ltd. liable for loss of, or damage to, a computer; or loss of, or damage to, a program,

records, or data; or any consequential or incidental damages.

● This product can be used for business purpose as registered by EMI compliance.

The information of manufacturer & copyright

"NextoDI", “NEXTO CARD BATCHER”, “NCB20”and "X-Copy" are registered trademarks of NextoDI Co., Ltd. "Sony", “SxS

PRO” and “SxS PRO+” are registered trademarks of the Sony Corporation. "Panasonic" and "P2/P2E" are registered

trademarks of the Panasonic Corporation. “CompactFlash” is registered trademarks of the Sandisk Corporation. “SD”,

“SDHC” and “SDXC” are registered trademarks of the SD-3C, LLC. "Windows" is a registered trademark of U.S. Microsoft

Corporation in the USA and other countries. "Mac OS" are registered trademark of Apple Inc. in the USA and other

countries. All other trademarks are the property of their respective owners. All company names and product designa-

tions are contained.

All companies and brand name mentioned in this article is for mere sorting and that each of its owned by its owner,

NextoDI does not have any right for that. For more inquiries, contact or consult our technical advisory service:

http://www.nextodi.com

This manual may change without prior notice to improve product performance. Reproduction of this manual in whole or

in part without prior written consent is prohibited.

Introduction

① NCB20 Main unit : Depending on which product you have purchased, you may have attached

V-mount Battery Plate (Pro model). If not, you purchased Basic model.

② AC Power Adapter (12V/2A): This is used to provide operating power while NCB20 is in use.

③ USB3.0 cable : This is used to connect NCB20 to the computer

④ User Guide

⑤ V-mount battery plate (Optional)

1. Contents of the ProductTable of Contents

1. CONTENTS OF THE PRODUCT

2. DEVICE DIAGRAM

3. PRODUCT DESCRIPTION

4. SYMBOLS USED IN THIS DOCUMENT

5. SAFETY INSTRUCTIONS

6. POWER MANAGEMENT

7. BASIC FUNCTIONS

8. CONNECTING MEMORY CARDS AND USB DRIVES

9. MODE SELECTION

9.1 MODE SELECTION

9.2 COPY MODE

9.3 CARD READER MODE

9.4 DELETE CARD MODE

9.5 VERIFY SUCCESSFUL BACKUPS

10. MANAGING MEMORY CARDS AND USB EXTERNAL DRIVES

11. VIDEO/AUDIO PLAYBACK AND PHOTO VIEWING

12. CHECKING WHAT YOU HAVE BACKED UP

13. SYSTEM PREFERENCE

14. TROUBLESHOOTING

15. TECHNICAL SPECIFICATIONS

1. Main Package

Optional : NCB-20-101

Contents of Product

① DC_IN slot for AC power adapter unit. DC 6~25V, 2A.

② SD/Micro SD card slot : It can not be plugged in both SD card and Micro SD card at

the same time in one slot

③ USB 3.0 host port : USB Port for connecting external HDD. [USB#1], [USB#2] It supports two

USB external HDD simultaneously through two ports

④ Computer interface port : This port is used to connect to a computer and use it as a

USB card reader, or to receive power from a USB cable from a USB Power Bank

⑤ LCD display

⑥ Control Button: Controls the movement of the cursor up / down / left / right and the function

in power ON state

⑦ Power Key: When the power is off, press the button for 2 seconds to turn on the power.

If the NCB20 does not operate normally, press and hold the button for 7 seconds to turn

off the NCB20 in any case

⑧ Power on LED: Green lights when power is on

⑨ Action LED: Red lights when USB storage device or memory card is in operation

3. Product Description2. Device Diagram

0302

NEXTO CARD BATCHER (hereinafter NCB20) provides following functions.

3.1. Memory card backup and verify

Card copy and verification must be done after connecting external power or external battery.

This function backs up the contents of the memory card to a USB external drives. Refer to

‘8. Connecting Memory Cards ’ and ‘9. Mode Selection’.

3.2. Card Reader

The Card Reader Function works as a USB card reader by connecting to a computer. Refer to

‘9.3 Card Reader Mode’ for details.

3.3. Delete Card

Delete Card function must be used after connecting an external power supply or external battery.

You can delete all the contents of the connected memory cards at once. For complete backup

information, see chapter ‘8. Connecting Memory Cards’ and ‘9.4 Delete Card Mode’.

3.4. Playing Videos and View Photos

The NCB20 includes a video / audio playback function (optional) that allows you to check the

contents of video data backed up from supported memory card (SDHC / SDXC).

See ‘11. Video / Audio Playback and Photo Viewing’.

3.5. Easy Button Operation

All functions can be easily operated by using two buttons (Power & Control), and the operation

status can be checked through the LCD screen. For how to turn the power on and off

and how to operate the buttons, refer to ‘7. Basic Functions’.

3.6. Changing Device and Slot Names

Backup folder names are created based on the ‘Device Name’ and ‘Slot Label’. This name and

label can be changed in the ‘Setup’ menu for user preferences. Refer to ‘13. System Preferences’.

3.7. Checking The Usage Log

NCB20 saves the usage logs such as XCopy, MCopy and computer connection as LOG file

to the drive (USB external drive). To check the LOG file, you can check the drive (USB external drive)

by connecting it to your computer. Refer to ‘12. Checking What You Have Backed Up’.

Product DescriptiomDevice Diagram
