Page 1/16

MODEL 2PACD250

OWNER’S MANUAL

250 PINT COMMERCIAL DEHUMIDIFIER

Model 2PACD250

Power Supply 115V/60Hz/1Ph

Rated Input Current 5.3 amps at 65°F 60%RH

Rated Input Power 578 watt at 65°F 60%RH

The Air Volume 235CFM

Dehumidication Capacity (80°F / 60% RH) 140PPD

Dehumidication Capacity (90°F / 90% RH) 250PPD

Filter SUS304 washable

Power plug length 25ft

Drain hose length 20ft

Net weight 126 lbs

Unit Size (W×H×D) 23 x 33 x 22 inch

Refrigerant/Charge (OZ) R410A/24.7oz

PRODUCT PARAMETER TABLE

IMPORTANT SAFETY INSTRUCTION 4 .............................................................................................

SAFETY TIPS 4 ..................................................................................................................................................................................

NOTICE OF OPERATION 4 ............................................................................................................................................................

IDENTIFICATION OF PARTS 5 .............................................................................................................

PRODUCT DESCRIPTION 5 ..........................................................................................................................................................

INSTALLATION GUIDE................................................................................................................................................................. 6

OPERATING INSTRUCTIONS 7 ............................................................................................................

CONTROL PANEL 7 .........................................................................................................................................................................

CONTROL PANEL FEATURES 8 ..................................................................................................................................................

BUTTONS 8 ..............................................................................................................................................................................................................................

ICONS 9 .....................................................................................................................................................................................................................................

POWER-ON AUTOMATIC DETECTION 11 ...............................................................................................................................

COMPRESSOR PROTECTION FOR THREE MINUTES 11 ...................................................................................................

POWER-DOWN MEMORY FUNCTION 11 .................................................................................................................................

APP CONTROL 11 ............................................................................................................................................................................

ADJUST THE HEIGHT HANDLE 12 .............................................................................................................................................

CLEANING THE AIR FILTER 12 .....................................................................................................................................................

TROUBLESHOOTING........................................................................................................................13

WIRING DIAGRAM.......................................................................................................................................................................13

ERROR CODES 13 ............................................................................................................................................................................

BOM 14 .................................................................................................................................................................................................

PARTS LIST 15 ...................................................................................................................................................................................

TABLE OF CONTENTS

IMPORTANT NOTE:

Read the manual carefully. Make sure to save this manual for future reference. Illustrations in this manual

are for explanatory purposes only, your actual product may look slightly dierent.

Stand dehumidier upright for full 24 hours before

initial start up to allow refrigerant to settle.

Always use and store dehumidier in an upright position.
