Page 1/16

MODELS

RD060, RD120,

RD060-O, RD120-O

GB1, GB2, GB3, GB4

INSTALLATION AND OPERATION INSTRUCTIONS

ARCTICPOUR ADVANCED REFRIGERATION TECHNOLOGY

IMPORTANT INFORMATION

To register your product, visit our web site at www.

perlick.com. Click on Commercial, then Service.

You will see the link to Warranty Registration Form.

You must complete and submit this form or the

installation date will revert back to the ship date.

Permanently mount the enclosed Warning/Safety

Instruction label in a visible location near the CO2

regulator.

This manual has been prepared to assist you in the

installation of your Century Remote Beer System and

to acquaint you with its operation and maintenance.

We dedicate considerable time to ensure that our

products provide the highest level of customer

satisfaction. If service is required, your dealer can

provide you with a list of qualified service agents. For

your own protection, never return merchandise for

credit without our approval.

We thank you for selecting a Perlick product and assure

you of our continuing interest in your satisfaction .

8300 West Good Hope Road • Milwaukee, WI 53223 • Phone 414.353.7060 • Fax 414.353.7069

Toll Free 800.558.5592 • E-Mail perlick@perlick.com • www.perlick.com

Table of Contents

Dimensional Drawings ............................................... 2

Product Description ................................................... 5

Installation ................................................................. 5

Important Safety Warnings .................................... 5

Installing the System ............................................. 5

All Models ......................................................... 6

Connecting to a Trunk Housing ............................. 6

Connecting Trunk Housing to Dispensing Head .... 6

System Pak Start-Up ................................................. 6

Digital Temperature Controller ................................... 7

Preventative Maintenance ......................................... 9

Replacement Parts .................................................... 9

Wiring Diagrams ...................................................... 11

Form No. Z2339

Rev. 11.30.2022

Refrigeration Deck

Glycol Bath

Perlick is committed to continuous improvement. Therefore, we reserve the right to change specications without prior notice

ARCTICPOUR

Operation/Installation Manual

Air-Cooled Refrigeration Deck

Permanently Connected Cord Connected

MODEL NOS. RD060 RD060-O RD120 RD120-O RD060-C

DIMENSIONS:

EXTERIOR (mm)

Length 31-1/2” (800) 35-15/16” (913) 34-3/8” (873) 38-15/16” (989) 31-1/2” (775)

Width 17-3/8” (441) 28-1/4” (718) 21-3/4” (552) 33-3/8” (848) 17-3/8” (445)

Height 15-3/16” (386) 15-3/16” (387) 18-1/16” (459) 18-1/16” (459) 15-3/16” (386)

A minimum of 12” of clearance should be allowed around the entire unit for proper performance. Additional clearance should be considered for

above and in front of the unit for serviceability.

ELECTRICAL Voltage 120 V 120 V 208/230 V 208/230 V 120 V

Frequency 60 Hz 60 Hz 60 Hz 60 Hz 60 Hz

Phase 1 Ø 1 Ø 1 Ø 1 Ø 1 Ø

RLA 11.5 11.5 19.3 19.3 11.5

MCA 18.4 18.4 23.8 23.8

Max Fuse 30 30 40 40

Cord/Plug N/A N/A N/A N/A 14/3 NEMA 5-15P

COMPRESSOR 3/4 HP 3/4 HP 1.5 HP 1.5 HP 3/4 HP

EVAPORATOR RATING

@ 20°F (BTUH)

6000 6000 12000 12000 6000

HEAT REJECTION (MAX) 8100 8100 16800 16800 8100

REFRIGERANT R-134a R-134a R-134a R-134a R-134a

SHIPPING WEIGHT LBS (kg) 120 (54) 120 (54) 140 (64) 140 (64) 120 (54)

CABINET Stainless Steel

REFRIGERATION Constant Pressure Expansion Valve, Condensing Unit with Service Valves

REFRIGERANT CHARGE (grams) 14.0 oz/397 g 14.0 oz/397 g 16 oz/453 g 16 oz/453 g 14.0 oz/397 g

Glycol Bath

Permanently Connected Cord Connected

MODEL NOS. GB1 GB2 GB3 GB4 GB1-C GB2-C

DIMENSIONS:

EXTERIOR (mm)

Length “A” 24-3/4” (629) 24-3/4” (629) 24-3/4” (629) 24-3/4” (629) 24-3/4” (629) 24-3/4” (629)

Width “B” 19” (483) 23-11/16” (602) 23-11/16” (602) 23-11/16” (602) 19” (483) 23-11/16” (602)

Height “C” 25-5/16” (643) 25-5/16” (643) 25-5/16” (643) 25-5/16” (643) 25-5/16” (643) 25-5/16” (643)

A minimum of 6” of clearance should be allowed around the entire unit for proper performance. Additional clearance should be considered for

above the unit and in front of the unit for servicability.

ELECTRICAL Voltage 120 V 120 V 120 V 120 V 120 V 120 V

Frequency 60 Hz 60 Hz 60 Hz 60 Hz 60 Hz 60 Hz

Phase 1 Ø 1 Ø 1 Ø 1 Ø 1 Ø 1 Ø

RLA 6.5 12.6 18.7 24.8 N/A N/A

MCA 7.6 13.6 19.6 25.6 N/A N/A

Max Fuse 15 20 25 30 N/A N/A

Current/Plug N/A N/A N/A N/A 6.5, NEMA 5-15 12.6, NEMA 5-20P

SHIPPING WEIGHT LBS (kg) 140 (64) 140 (64) 140 (64) 140 (64) 140 (64) 140 (64)

CIRCULATING PUMP #1 140 GPH / 130 PSIG

CIRCULATING PUMP #2, #3, #4 100 GPH / 130 PSIG

RESERVOIR CAPACITY 12 gal

GLYCOL CONCENTRATION 30% 30% 30% 30% 30% 30%

67451 Coolant Connector Parts Bag, Refrigeration Deck to Glycol Bath 61790+1 Rack, 37” X 19-3/4”, 3-Tiered

67451-1 Coolant Connector, Fabricated, Per Foot, Refrigeration Deck to Glycol Bath 61790+2 Rack, 37” X 19-3/4”, 4-Tiered

63299-1 Glycol Solution, 1 gallon 57782 Legs, Set of 4, 6” Nom

63335 Coolant Connector Kit (Glycol Bath to Trunk Housing) 68470-1 Wall Shelf, Large (RD120)

63335-1 Coolant Connector Kit (Glycol Bath to Trunk Housing) 68470-2 Wall Shelf, Small (RD060 or GB)

68455 Flashchill Connector Kit 68508 Rack, ArcticPOUR, Two Tier

C21499BSS Stand, 35” X 22” 68508+1 Rack, ArcticPOUR, +1 Extension

61790 Rack, 37” X 19-3/4”, 2-Tiered 68508+2 Rack, ArcticPOUR, +2 Extension

ACCESSORIES

Perlick is committed to continuous improvement. Therefore, we reserve the right to change specications without prior notice

ARCTICPOUR

Operation/Installation Manual

Form No. Z2339

Rev. 11.30.2022

1:12

J:\Dwg\95000\95077

SCALE

4/9/2012

Milwaukee, WI 53223

DRAWN

Perlick Corporation

95077

OR MECHANICAL, INCLUDING PHOTOCOPYING, RECORDING, OR USED IN ANYINFORMATION STORAGE, TRANSMISSION, OR RETRIEVAL SYSTEM, WITHOUT WRITTEN PERMISSION FROM THE PERLICK CORPORATION

MODEL GB#

THIS DOCUMENT/PUBLICATION/SOFTWARE/DRAWING CONTAINS PROPRIETARY INFORMATION WHICH IS THE PROPERTY OF THE PERLICK CORPORATION. IT MAY NOT BE REPRODUCED OR TRANSMITTED IN ANY FORM, ELECTRONIC
