Page 1/4
β’Single 4 Ohm Voice Coil
β’ 22mm Peak to Peak Excursion
β’ 1.5β High Temp Copper Voice Coil
β’ Easy Connect Speaker Terminals
β’ Black Anodized Aluminium Former
β’ Optimised for Sealed or Vented Enclosures
β’ Long Throw Spider Suspension
β’High Roll Rubber Surround
β’ Dual Cone Design
FEATURES
Models: Z8S4
8β HIGH PERFORMANCE SUBWOOFER
150W RMS - 450W MAX OUTPUT
All speciξcations are subject to change without notice.
Β© 2022 Phoenix Gold β’ www.phoenixgold-eu.com
SPECIFICATION Z8S4
Nominal Impedance (Z) 4 ohms (Single)
DC Resistance (Re) 3.72 ohms
Resonance Frequency (Fs) 40 Hz
Piston Area (Sd) 221.76cm2
Force Factor (BL) 10.314 Tm
Mechanical Q Factor (Qms) 7.839
Electrical Q Factor (Qes) 0.681
Total Q Factor (Qts) 0.626
Sensitivity 1W/M (SPL) 83.6
dB
Mechanical Compliance (Cms) 0.205 mm/N
Moving Mass (Mms) 77.586 g
Volume Acoustic Compliance (Vas) 14.223 Ltrs
Nominal Power (Pe) 150 Watts
Peak Power 450 Watts
Voice Coil Diameter 1.5in/38mm
Overall Diameter (A) 8.43in/214mm
Cut Out Diameter (B) 7.17in/182mm
Mounting Depth (C) 4.02in/102mm
B
A
C
Phoenix Gold Recommended Ampliξer Wattage (RMS)
MAXMIN
Optimal Input
RMS Wattage
Enclosure Recommendations
Speaker and port displacement are already taken into account for recommended
enclosures
Sealed Enclosure - Punchy Bass
Net Internal Volume 20 Ltr
Frequency (FSC) 120Hz
Ported Enclosure - Punchy Bass
Net Internal Volume 15 Ltr
Frequency (FB) 48Hz
Slot Port Area 56cm2
Slot Port Length 42cm
Round Port Diameter 3 inch (7.62cm)
Round Port Length 33cm
Sealed Enclosure - Hi-Fi Bass
Net Internal Volume 30 Ltr
Frequency (FSC) 101Hz
Round Port Example
Ported Enclosure - Hi-Fi Bass
Net Internal Volume 24 Ltr
Frequency (FB) 40Hz
Slot Port Area 39cm2
Slot Port Length 25cm
Round Port Diameter 3 inch (7.62cm)
Round Port Length 29cm
Twin Box Enclosure - Punchy Bass
Net Internal Volume 30 Ltr
Frequency (FB) 45Hz
Slot Port Area 76cm2
Slot Port Length 30cm
Round Port Diameter 2x 4 inch (10.16cm)
Round Port Length 32cm
