Warnings and Cautions
1of1
Assembly Instruction Sheet #IS-TFAS9470VA
For Style TFAS9470VA
6 CORPORATE PARKWAY
GOOSE CREEK SC 29445
www quoizel com
, .
. .
Thank you for purchasing a Quoizel product.
Need assistance with parts or assembly? Call Quoizel customer service at 1-631-273-2700
or visit us on-line at www.quoizel.com
2015 QuoizelInc. July2015
Turn off electricity at circuit breaker or main fuse box before installation. Consult a licensed electrician if in doubt.
These instructions are provided for your safety. It is very important you read them completely before installing the fixture. We strongly
recommend that a licensed, professional electrician perform the installation.
Disconnect fixture from power source before replacing bulbs. Make sure bulbs are given sufficient time to cool before removal. Do not subject
glass parts to any shock while in operation or shattering may result.
Care of Tiffany Style Shade
A new tiffany lamp shade has an oil film applied to the shade that protects the tiffany shade from scratches during shipment. If the oil applied is
too heavy you can remove the excess oil film with a paper towel. Gently wipe away the excess oil.
For general cleaning of tiffany shades use a gentle lemon oil-based furniture polish applied to a soft cloth and wipe gently.
If a white powder appears on the soldered joints of the tiffany shade this is a normal oxidation process. Use a small amount of lemon oil or
mineral oil applied directly to oxidized areas and the soldered area will return to like new.
TFAS9470VA
PART NUMBER
NOTE: ALL DIMENSIONS ARE ROUNDED
UP TO THE NEAREST 1/4"
REPLACEMENT PART DESCRIPTION
NO.
(1) 150W 3Way
Bulbs
(Not Supplied)
MediumBase
1
2
19470VATFAS
G12093SH
BASE
SHADE
REQ.
1
1
12” Sq.
FINISH: VALIANT BRONZE
Please go to for product cleaning tips. Go to the selection.
(1) A21 Medium Base 3Way 150W Maximum, Alternate bulb (1) 42W CFL
20-30 minutes
Identify and inspect all parts before beginning installation. Check package content list and diagrams below to be sure all parts are
present. If any parts are missing or damaged, do not attempt to assemble, install, or operate the fixture. Contact customer service for replacement
parts.
www.quoizel.com Care + Maintenance
Light Source:
EstimatedAssembly Time:
Preparation:
Tools Required: None.
A. Thread the Socket Assembly ,
the , the
and the Base together as
shown. Hand tighten until snug.
B. Pull the cord from the Base as
you assemble the parts
together to remove the excess
cord between parts.
C. Place the Shade over the
Socket, secure by threading
Socket Collar onto the Socket,
hand tighten until sung.
D. This fixture uses standard bulb
with medium base . Maximum
150 watts. Insert bulb and
screw snugly into place.
Your fixture is now assembled
and ready to use. Enjoy!
Rod Threaded Rods
Bulb (not
included)
Socket
Assembly
x 1
Base
x 1
Rod
x 1 Threaded
Rod
x 3
Socket
Shade
x 1
Socket
Collar
x 1 5.75”
70.5”
10.25” Sq.
2
1
